5-12mm Pre-Cast Floor Wire Welded Mesh Machinery

5-12mm Pre-Cast Floor Wire Welded Mesh Machinery

US$82,000.00
1 set
US$81,500.00
2 set
US$81,000.00
3+ set

Basic Info.

Model NO.
GWC-C-2000
Style
Horizontal
Warranty
1 Year
Frequency
50Hz
Number of Phases
Three Phase-Four Wire
Load Duration Rate
20%
Air Source Pressure
0.6-0.8MPa
Cooling Liquid Flow
50-150L/Min
Cooling Liquid Temperature
30 Degrees
Transport Package
Plastic Film or Components in The Wooden Box
Specification
total mesh width: 1200-3300mm(customized)
Trademark
yizhou
Origin
China
HS Code
84633000
Production Capacity
100 Sets/Year

Product Description

Product Description
Wire mesh welding machines are advanced equipment used for manufacturing wire mesh products.
These machines efficiently weld wires together to create strong and durable mesh panels.
They are widely used in various industries such as construction, agriculture, mining, and fencing.
The functionality of wire mesh machines includes precise wire alignment, automatic welding, and adjustable mesh sizes.
These machines ensure high productivity, consistent quality, and cost-effectiveness in producing wire mesh for applications like security fencing, reinforcement mesh, animal enclosures, and industrial partitions.
Product Parameters
Max.Welding Capacity
φ12mm+φ12mm
Welding Speed
50-90rows/min
Cross Wire Spacing
≥50mm(step-less adjustment)
Rebar Diameter
φ4-6mm/φ6-12mm
Feeding Method
Cross wire-bar; line wire-coil
Unloading/Output Method
By unloading machine
Line Wire Spacing
φ6-12mm:≥100mm(increments 50) ; φ4-6mm:≥50mm(increments 50)
Rated Power
GWC-C-3300
16x150kVA
GWC-C-2800
14x150kVA
GWC-C-2400
12x150kVA
GWC-C-2000
10x150kVA
GWC-C-1600
8x150kVA
GWC-C-1200
6x150kVA

Detailed Photos
Line wire manual feeding(the line wire is the pre-cut straightening bar)
Cross wire automatic feeding(the cross wire is the pre-cut straightening bar)
Welding
Welded Mesh
Finished wire mesh
Welcome any inquiry!
If you have any questions or comments,please feel free to contact us.
Wire mesh welding mhines are advanced equipment used for manufacturing wire mesh products. These machines efficiently weld wires together to create strong and durable mesh panels. They are widely used in various industries such as construction, agriculture, mining, and fencing. The functionality of wire mesh machines includes precise wire alignment, automatic welding, and adjustable mesh sizes. These machines ensure high productivity, consistent quality, and cost-effectiveness in producing wire mesh for applications like security fencing, reinforcement mesh, animal enclosures, and industrial partitions. For inquiries or visits, please feel free to contact us. We welcome the opportunity to assist you
