Manufacturer Supply Best Selling Fertilizer Granulator/Food / Pharmaceutical Drying Machine/ Mixing/Spray/ Oscillating/Extruder/Rapid Mix Fluid Bed Granulator

Product Description

Product Parameters

Spec			3	5	30	60	120	200	300	500	1000
item		unit
container raw material	dim	mm	300	400	700	1000	1200	1400	1600	1800	2200
	volume	L	12	22	100	220	420	670	1000	1500	2500
production capacity	min	Kg/batch	1.5	4	15	30	80	100	150	250	500
	Max	Kg/batch	4	6	36	72	140	240	360	600	1100
consume of steam		Kg/batch	12	23	70	140	211	282	366	465	800
amount of compressed air		m 3 /min	0.3	0.3	0.3	0.6	0.6	0.9	0.9	0.9	1.5
power of fan		kw	2.2	4	5.5	11	18.5	22	30	45	75
temperature			Adjustable from ambient to 120
collection rate		%	>99
time of operation		min	15-30 (depends on material)
content of final product		%	0.2 (depends on material)
noise		db	≤75
height of main machine		mm	2100	2300	2500	3000	3300	3800	4000	4800	6200

Product Description
"YIBU" considers that Fluiding drying machine is an organic combination of mechanical design and manufacture technology. Therefore hundreds of Granulating machines either for China or exported to USA, Japan, Indonesia, Iran and many other countries are designed in accordance with the process of raw materials.
We have manufactured decades specifications and 150 different machines to meet different needs. These practical experiences will be very beneficial to customers.
The flow ability is improved and the dust is reduced, because of Granulator.
Because of powder Granulating, its solubility is improved,
Mixing, Granulator and drying processes are completed in one step inside the machine.
The operation is safe because the anti-static filter cloth adopted.
It's safe for operator if explosion take place, because explosion device is adopted.
No need corner. Therefore the loading and unloading are quick, light and clean, meet the requirements of GMP.
Pharmaceutical industry: Tablet capsule, low sugar or no sugar granule of Chinese traditional medicine.
Foodstuff: Cocoa, coffee, milk powder, juice of granulate, flavoring and so on.
Other industries: Pesticide, feed, chemical fertilizer, pigment, dyestuff and so on.
Drying: Powder or granule state of wet material
Coating: Protection layer, color, controlled release, film, or bowels solved coating of granules and pills.
The powder granule in vessel (fluid bed) appears in the state of fluidization. It is preheated and mixed with clean and heated air. At the same time the solution of adhesive is sprayed into the container. It makes the particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.
Company Profile
Changzhou Yibu Drying Equipment Co., Ltd is a leading manufacture of drying, mixing, granulating equipemnt in the main land of China, a specially- designated enterprise of China Association of Pharmaceutical Equipment and China General Chemical Equipment Corporation, covers more than 50, 000sq. M, holds RMB 38 million of fixed assets and has more 180 sets of special processing equipment and powerful technical force, own the provincial famous trademark "YIBU". It can produce more 1, 500 stes of different. At present, there are 28 kinds and over 160 of specifications and varieties. The credit level is AAA for the passing days. ISO9001 & ISO1400 are approved.
The founder, Mr Zha Guocai devotes research, manufacture, production and business of drying equipment for over thirty years, holds the post of Deputy Director-General of China Drying Equipment Association for a long time.
The company pays much attention to science and technology renovation. First or later, it has cooperated with the institutes that are Shanghai, Wuhan, Chongqing and so on, and cooperated with Shenyang Chenmical Institute, Ministry of Chemical Industry, Qinghua University, Shanghai transportation University, Dalian Science and Technology University. Therefore the company can put 3-5 new varieties into the market every year. In 1998, through approval of state relevant departments, the company set up China Research Center of Drying and Granulating, that can research new process and develop new technology and provide new products for pharmaceutical, chemical and foodstuff industries. We have many testing machine in our lab for to make trials for clients.

We've sold equipment to USA, Mexico, Columbia, Guatemala, Brazil, Peru, Australia, New Zealand, Ghana, Russia, Cyprus, Greece, Iran, Indonesia, Philippines, Korea, Japan, Taiwan, Hongkong and so on totally nearly 50 countries and districts around the planet.
