Feihong Brand Electrostatic Spray Epoxy Polyester Ral Color Pintura En Polvo Powder Coating

Product Description

FEIHONG brand Electrostatic Spray/Tribo Matt Epoxy Polyester Ral/Color Powder Coating Powder
Powder Coating for aluminium extrution
Powder Coating for racking system
Powder Coating for electric cabinet
Powder Coating for exterior fence
Powder Coating for metal furniture
Powder Coating for metal door
Product Description
COLORS FOR POWDER COATING/POWDER PAINT RAL colors powder coating powder paint Pantone colors powder coating paint Color-matching regarding customer requirement available GENERAL TYPES
Polyester / Hybrid powder coating powder paint Pure Epoxy Powder coating color/FBE powder coating Metallic powder coating color Hammer tone powder coating Fine Texture color powder coating & powder paint Textures include sand grain, hammer vein, silk pattern, sand textured, marble,metallic, multi-color.
PHYSICAL PROPERTIES
Specific gravity :1.2 ~ 1.5g/cm3 on base of defferent colors Particle size distribution:100% less than 100 microns (depending on the specific indicators art effects may be, according to the special requirements of painting adjusted) Level of liquidity:24 ~ 27 mm CURING CONDITIONS
180 °C ~ 200 °C (work piece temperature) for 10 to 15 minutes
Powder Coating Application
Powder Coating for aluminium extrusion
Powder Coating for racking system
Powder Coating for electric cabinet
Powder Coating for gas cylinder
Powder Coating for exterior fence/road fence
Powder Coating for metal furniture
Powder Coating for iron/steel door
AVERAGE COVERAGE
8-12 square meters per kg, thickness 60-90 microns (100% of the powder coating utilization rate)
PACKING
Outside carton lined with two layers of polyethylene bags, each contain 20kgs or 25kgs N.W.

STORAGE AND TRANSPORT
Stored in less than 30 °C, ventilated, dry, clean room, not near the fire source, heating, avoid direct sunlight, the product in the transport should be to prevent rain, sun, prolonged sun exposure.Storage products in line with the above conditions, since the date of production, effective storage period is 6 months.Over the storage period may be re-tested and the results were consistent with, can still be used.

HEALTH AND SAFETY
Coating powder is a non-toxic products, but should be avoided in the course of inhalation of dust.Proposed operators wear appropriate dust mask, glasses.If possible, try to avoid long-term skin contact with powder coating

Mechanical property
Testing items	Standards and methods	Inspecting index
Impact strength	GB/T1732-1993, AS3715 2.8	>50kg/cm
Bending resistance	GB/T1185-88, AS1580 402.1, ISO9227	Pass 2-5 millimeters
Adhesion CHECKED TEST	GB/T9286-88,2mm Cross cut, ISO2409	Pass100/100, passes 0 levels
Cupdrawing:Erichsen, ISO1520	Erichsen, ISO1520	Pass 3-7 millimeters
Pencil hardness	GB/T6739-86, Mitsubishi	Pass 1H to 2H
Chemical resistance and weather resistance
Salt spray test	GB/T1771-91,500 hours	The cross section of corrosion less than 2MM
Hot and damp resistance test	GB/T17740-79(89),1000 hours	Without air bubbles, loses the light slightly
Acid resistance	10% CH3COOH, 240 hours	Without air bubbles, the surface without damage
Alkali resistance	10% NaOH, 240 hours	Without air bubbles, the surface without damage
Heat resistance	200degree,1 hour	The color change is lower than E=1.5
Solvent resistance	MEK24 hours soaked in solvent-free	Without air bubbles, the surface without damage
Uvioresistant	QUV-313,500 hours	Gloss higher than 80% lower than the Munsell color change level
Water tolerance of	2 hours	No bubble, not falling, losing gloss

We offer free samples to you.
