US$2,800.00-18,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Type
Surface Grinding Machine
Processing Object
The Knife for Veneer Production Machine
Automatic Grade
Automatic
Cylindrical Grinder Type
Universal Cylindrical Grinder
Product Name
Automatic Knife Grinding Machine
Application
Grinding Knife/Blades of Veneer Peeling Machine
Table Size
1550X180(200)mm
Max Grinding Length
1500-2800
Grinding Wheel Size
200*100*32mm
Work Voltage
80V / 440V ( Can Be Customized )
Adjustable Angel of Work Table
90
Grinding Wheel Reciprocating Speed
17m/Min
Knife Grinding Method
Electromagnetic
Core Components
Motor, Bearing, Engine, Gear, Pressure Vessel
Video Technical Support
Available
Voltage
380V or Customizable
Transport Package
Standard Exporting Package
Specification
3850*1300*1300mm
Production Capacity
200sets / Month
Product Description
Hot sale product blade sharpening machine knife grinding machine knife grinder Product Description
Features:
1. This machine mainly grind all type of long knives, like peeling machine knife, Granulator knife,cutting paper knife ,Shearing Blades, sliceing knives etc.
2. This machine can work long surface knife. Max. Working length is 1500mm.
3. This machine's body is a design of gantry body, with the high-quality steel weld,The body has high strength and good rigidity.
4. The worktable use the electro magnetic chuck. And very convenience to clamp knife. The worktable is easy to adjust the angle by worm gear.
5. This machine use the inverter. It can be easy to adjust the horizontal and vertical speed of the grinding head.
6. Job accuracy of machine is 0.01mm.
Product Parameters
Electromagnetic Automatic Knife Grinder
|
Model
| GTCO1500
| GTCO3000
| GTCO3500
|
Max Grinding Length
| 1600 mm
| 3200mm
| 3600mm
|
Table Size
| 1550x180(200)mm
| 3000x180(200)mm
| 3550x180(200)mm
|
Total power
| about 6.0kw
| about 6.0kw
| about 6.0kw
|
GTCO1500
|
Max grinding length
| 1600mm
|
Table size
| 1550x180(200)mm
|
Grinding wheel size
| Φ200*Φ100*Φ32mm
|
Work voltage
| 380V / 440V ( can be customized )
|
Grinding wheel reciprocating speed
| 17m/min
|
Adjustable angel of work table
| ±90°
|
Driving method of grinding head
| Transmission
|
Overall dimension
| 3850*1300*1300mm
|
Total power
| 6kw
|
Total weight
| 1800kg
|
Detailed Photos
