9-32mm Pet Plastic Steel Belt Production Line in 100% Bottle Flakes

Product Description

Product Description
PET strapping machine is an industrial equipment used to make polyethylene terephthalate (PET) strapping, which is widely used for packaging and strapping in various industries such as logistics, construction, steel, aluminum, chemical fiber, cotton spinning, etc.
PET strapping is a strong and environmentally friendly alternative to steel strapping and PP strapping, with its high tensile strength, flexibility and recyclability as its advantages.
Applications: Mining Industry: Used for transporting heavy and abrasive materials such as coal, ore, and minerals.
Cement Industry: Ideal for conveying raw materials and finished products in cement plants.
Steel Industry: Suitable for handling steel coils, scrap, and other heavy materials.
Power Plants: Used for coal handling and ash disposal.
Ports and Terminals: Efficient for bulk material handling and loading/unloading operations.
PET packaging belt production line process flow
Loading →Mixing raw materials → Pre-drying raw materials → Vacuum dehumidification of raw materials →Melting and metering extrusion of raw materials →Cooling and forming of raw materials (with raw materials) →Preheating the oven → Primary stretching →Secondary stretching → Embossing → Oven tempering and shaping →Cooling →Finished product winding

Model	PET-2	PET-3	PET-4	PET-6	PET-8
Raw materials	Bottle flakes/crushed materials
Number of tapes	2	3	4	6	8
Width (mm)	9-32
Width (mm)	0.4-1.2
Maximum line speed(m/min)	>=150	>=150	>=150	>=150	>=150
PLC control system	PLC	PLC	PLC	PLC	PLC
Screw Model	90	100	125	150	180
Reducer model	200	250	280	315	350
Dryer tank	3000L	4000L	5000L	6000L	6000L
Dehumidifier	1000	1000	2000	3000	3500
Metering Pumps	100CC	100CC	100CC	100CC	100CC
Screen Changer	Single cylinder
Production capacity /24 H	5-6T	7-8T	10-12T	12-15T	18-20T

Detailed Photos
Advantages of PET plastic steel belt equipment:
Economical and efficient: long service life, low maintenance requirements, high degree of automation, it is an economical and efficient equipment for packaging materials.
Efficient: high strength and durability ensure efficient material handling, sustainable production, and reduced downtime.
Safety: The sturdy structure ensures safe and reliable operation and minimizes the risk of belt failure.
Energy saving: energy saving and environmental protection, high output and low power consumption.

The PET strapping machine can be customized in size according to the customer's factory requirements.
The PET strapping production line can be produced using 100% bottle flakes or 100% PET crushed materials, which is energy-saving and environmentally friendly with low manufacturing costs.

FAQ
Q: What is the voltage of the PET plastic steel belt equipment?
A: 380V/50HZ, three-phase (customization supported)
Q: What is the extrusion capacity of the PET plastic steel belt equipment?
A: Different models have different extrusion capacities, ranging from 150-600KG/H
Q: Where does the PET plastic steel belt equipment come from?
A: China.
Q: What are the certifications for PET plastic steel belt equipment?
A: ISO CEO certification.
Q: What is the minimum order quantity for PET plastic steel belt equipment?
A: 1 set
Q: What is the weight of the PET plastic steel belt equipment?
20T, 40GP container * 3PCS
