Compact Self-Propelled Hydraulic Scissor Lift for Warehouse Operations, Construction and Maintenance
| US$5,000.00-20,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
(JCPTZ610HD)
Application
Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism
Scissor Lift
Carrying Capacity
Middle-Level
Moves
Moving
Driven Type
DC
Running Mode
Moving
Feature
Explosion-Proof
Certification
CE
Working Height
8m
Ground Clearance
0.2m
Lifting Height
6m
Charger
24V/30A
Transport Package
Standard Export Package
Specification
CE
Trademark
LINLIFT
Origin
China
HS Code
842810900
Packaging & Delivery
Package Size
248.00cm * 85.00cm * 173.00cm
Package Gross Weight
1880.000kg
Product Description
Introducing our robust 500kgs 6m Electric Scissor Lift, complete with the prestigious CE Certificate (Model: JCPTZ610HD). Experience unmatched quality and efficiency!JCPTZ610HD
1. Safe Working Load (S.W.L) of an impressive 500kg, ensuring your operations are worry-free and secure!
2. Reaching up to a remarkable working height of 8 meters, this lift provides the ultimate elevation for all your needs.3. Perfectly designed for accommodating two persons comfortably, enhancing productivity and collaboration. 4. Exceptionally convenient and practical, crafted to simplify your tasks with maximum ease and functionality.5. Enjoy our highly regarded, reliable after-sales service, providing you peace of mind and continuous support.
| Machine specifications | ||||
| SPECIFICATION | JCPTZ610HD | JCPTZ810HD | JCPTZ1010HD | |
| Weight | 2150KG | 2200KG | 2300KG | |
| Overall height | 2.19m | 2.32m | 2.45m | |
| Overall width | 1.15m | |||
| Overall height | 2.48m | |||
| Maximum slope | 1.5-3° | |||
| Gradeability | 25% | |||
| Maximum Drive Speeds-Stowed | 2.5Km/h | |||
| Maximum Drive Speeds-Raised | 0.8Km/h | |||
| Ground clearance | 0.1m | |||
| Wheelbase | 1.9m | |||
| front wheels | 381*127 | |||
| Back wheels | 381*127 | |||
| Electrical specifications | ||||
| SPECIFICATION | JCPTZ610HD | JCPTZ810HD | JCPTZ1010HD | |
| Batteries | 4-6V/250Ah | |||
| Integrated charger | 24V/25A | |||
| Drive motors | / | |||
| Lifting motor | / | |||
| Lifting motor | 24VDC/3KW | |||
| Platform Data | ||||
| SPECIFICATION | JCPTZ610HD | JCPTZ810HD | JCPTZ1010HD | |
| S.W.L | 500KG | 450KG | 320KG | |
| S.W.L on extension | 112KG | |||
| Platform size | 2.27*1.12m | |||
| Platform extension size | 1.2m | |||
| Working height | 8m | 10m | 12m | |
| Plaform floor height | 6m | 8m | 10m | |
| Up/Down speed | 45/30sec | 55/40sec | 70/60sec | |
