Marble Gantry Grinder Grinding Marble Workpiece

Product Description

The name of the machine: CNC shaping grinding machine
Machine specifications:Crm-315
Machine images:

CRM-315 CNC blade grinder is the leading variety developed by our company itself. It is designed for the screw rotor manufacturing industry. Supporting the knife grinding machine tool. Designed (milling molding tool) The blade mill uses a program to simultaneously sharpen the front and rear corners of all the blades on the blade. The machine tool uses the universal CNC system blade mill special version software.
Structure and main technical parameters of CRM315
I. Structural characteristics of the machine tool: 1. The machine tool adopts the gantry structure (fixed beam moving platform), and the bedside box and tail seat are installed on the worktable to support the knife body. The workbench is reciprocated through the ball-screw bars. 2. The machine tool adopts the ball line guide rail, with high positioning accuracy, fast moving reaction, low speed feed and good crawling stability. 3. Machine rail lubrication is lubrby centralized intermittent special lubrication pump and timely. 4. The feed shaft [Z, X and Y axis] adopts high precision ball wire directly driven by wide servo motor, with high transmission accuracy and good positioning accuracy. 5. The bedside C-axis adopts broad servo motor direct connection and high-precision worm worm worm (this worm worm is the gap worm worm, and the side gap can be adjusted and adjusted). 6. The grinding wheel spindle is driven by the electric spindle to achieve the infinite variable speed. 7. The machine tool is equipped with a high-pressure water pump, which realizes the cooling effect through forced cooling during processing. 8. The electrical components in the electrical control cabinet of the machine tools all adopt Delixi brand. 9. The machine tool is equipped with a machine tool protective cover.

project	content	unit
Machine tool use	Grinding cutting tool
The length of the lathe bed	1300	mm
Bed width	1200	mm
Cutter diameter	Φ150 -Φ315	mm
Grinding tool material	Alloy tool superhard tool steel, etc
Grinding head spindle power	550(reference)	W
Grinding head spindle speed	2500-2800	r/min
Grinding wheel material	CBN
Servo control shaft number	ool rotation (C axis)
	Beam (Y-axis)
	Sliding platform down (Z axis)
	Table (X axis)
Numerical control system	Wide number
