Raise 3.0-5kw Power Electric Start Portable Diesel Generator Set Prices

Product Description

Product performance:
As a national high-tech enterprise, RAISE has extensive research in the development and production of generator sets.All units are equipped with durable thick tube frame, making the units more beautiful, compact and strong.We are also pursuing technological innovations actively to reduce pollutant emissions and fuel consumption.
1. Control panel: The new diesel generator set includes a patented control system.More fully reflect the operating state of the unit.
2. Real-time data display: The display in the control panel displays the working data of the generator set in real time, such as output voltage, frequency, running time, battery voltage, etc.
3. Low oil alarm system: When the oil is insufficient or deteriorates for too long, the generator set will shut down automatically.It can only be started after refueling.
4. New automatic voltage regulator: AVR (automatic voltage regulator) not only can ease the output, but also can implement appropriate protection for the overload of the whole unit to avoid damage to the unit.
5. Starting mode: A convenient manual or electric start enables the new diesel generators to be quickly started up and running.
Product Description:

Model

Technical Parameters

3GF-LH/E

Unit structure: frame type Rated power: 3.0KW Maximum power: 3.3KW Rated frequency: 50Hz Rated voltage: 220V Excitation mode: AVR automatic adjustment Fuel tank capacity / working time: 12L / 8.5 hours Engine model: RZ178FA/E Engine form: single cylinder four stroke air cooling Cylinder diameter × stroke: 78 × 64 Displacement: 305cc Fuel type: summer 0#, winter-10# Lubricant model: SAE15W/30 Lubricating oil capacity: 1.1L Start mode: hand start / electric start Battery capacity: 20Ah Unit size: 645 × 490 × 550mm Packing size: 665 × 510 × 570mm (carton) Net weight / gross weight: 76/79 Kgs

RAISE Advantage:
Company Information:
Certifications:
FAQ:
