Single Mast Aerial Work Platform Max Height of Platform (8m)

Product Description

Single Mast Aerial Work Platform
Company introduction: Boonai Lift Equipment Co. Ltd as a modern manufacturing enterprise is specialized in aerial workplatform, providing package service for design, production, sales and after-sales.There is an experienced team that takes care of every process for design, production and qualitycontrol and dedicated to provents with excellent work.With business philosophy of "Quality First, Client Oriented", we are striving for building a reputablebrand of Boonai by following the steps of the giants for the innovation of products and theimprovement of process and pursuing the perfection on every detail.Main products are as follows: masts aerial work platform, scissor lift, fixed lift table, car lift andmaterial picker as well as electrical aerial work platform, with a wide application for the fields asmachinery, military, aviation and logistics etc. Product introduction: • Application: for single passenger.
• Features: small footprint, less weight, easily moved, able to access to limited
passageway, the most ideal equipment for aerial work to replace ladder or rigger,
with high efficiency and more security.
Standard Configuration
• Power supply: single phase AC(AC220V).
• Move mode: manual(default).
• Driving unit: one unit hydraulic pump, small volume and less noise.
• Others:
1. Leveling of platform is guaranteed by adjusting outrigger with screws.
2. Electric limit switch shall cut off power when up limit is reached.
3. Ground/platform control modes are available, rendering possibility of one operator.
4. Stroke protection block is build in hydraulic cylinder for security.
5. Emergency lowering system is equipped.
6. Antiskid staircase is provided.
7. Leveling indictor is equipped.

• Parameters

Model	GTWY4-100	GTWY6-100	GTWY8-100	GTWY9-100	GTWY10-100
Safe working load(kg)	150	150	125	125	125
Number of passengers	1	1	1	1	1
Max height of platform(m)	4	6	8	9	10
Max working height(m)	5.7	7.7	9.7	10.7	11.7
Overall length (m)	1.05	1.32	1.32	1.38	1.42
Overall width(m)	0.75	0.80	0.80	0.85	0.85
Overall height (m)	1.65	1.65	1.98	1.98	2.10
Extended outrigger(lxw)(m)	1.76*1.64	1.76*1.63	1.76*1.75	1.98*1.83	1.91*1.81
Size of platform(m)	0.60*0.55	0.60*0.55	0.60*0.55	0.60*0.55	0.60*0.55
Lifting motor
AC(VAC/kw)	220/0.75	220/0.75	220/0.75	220/0.75	220/0.75
DC(option)(VDC/kw)	24/0.8	24/0.8	24/0.8	24/0.8	24/0.8
Accumulator(V/AH)	2*12/80	2*12/80	2*12/80	2*12/80	2*12/80
Charger(V/A)	24/10	24/10	24/10	24/10	24/10
Wheel
Front wheel (in)	6	6	6	6	6
Rear wheel (in)	6	6	6	6	6
Overall weight(kg)	185(AC) 230(DC)	260(AC) 305(DC)	300(AC) 345(DC)	326(AC) 372(DC)	350(AC) 395(DC)

• Optional Configuration

Power supply: Battery Dc with charger ,suitable for outdoor operation

Move mode: 1. Electric moving device is equipped in case of long distance travel

2. Could be built in carriage of truck

3. Trailer base could be provided in case of outdoor operation

Others:

1. Explosion-proof valve for oil tube

2. Insulated platform

3. Explosion-proof electrical system

4. Overload alarm

5. Outrigger limit switch

6. Tilt alarm

7. AC power to platform

8. Working alarm

9. Rubber dust stop

• Company Certificates
• Part or Customers
• Packing
• Warranty
1. User-friendly English manual for machine using and maintenance.
2. One year warranty for whole machine without man-made fault.
3. We will send you parts for free if there are any non-human factors problem during
warranty time.
4. 24-hours technical support by email, telephone or other communication online.
5. We could reply you in 2 hours after received your any questions even on weekend and
holidays engineers are available to your company if necessary.
