High Speed Thickness Gauge with CE Approved

Product Description

Product Description
The PW-TCK-T02 thickness gauge adopts a mechanical contact measurement method. The design of the whole machine strictly meets the requirements of the standard. It is professionally suitable for accurate measurement of the thickness of various materials such as plastic film, sheets, diaphragms, foil, silicon wafers, paper, etc.

Features
1. The contact area and measurement pressure are designed in strict accordance with the standard, and various non-standard customizations are supported;
2. Using high-precision thickness measurement sensors, effectively guarantee the accuracy and repeatability of the measurement data;
3. The measuring head is automatically raised and lowered, effectively avoiding system errors caused by human factors;
4. It supports manual and automatic modes, which is convenient for users to use;
5. The standard micro printer can realize real-time historical data printing function;
6. Standard gauge block is standard, which is convenient for users to calibrate the sensor and better guarantee the accuracy of measurement data;
7. The key components are imported from world-renowned brands to ensure the accuracy and stability of the system;
8. Imported high-speed and high-precision sampling chip to ensure the real-time and accuracy of test data;
9. 7-inch high-definition color LCD screen, convenient for users to control and display real-time data and curves;
10. Support historical data for quick viewing and report printing.

Product Parameters

Index	Parameter
Range	0~2mm (standard); 0~6mm, 0~12mm (optional)
Resolution	0.1um
Repeatability	0.3um
Test speed	1~25 times/min
Measuring pressure	17.5±1 KPa (film); 50±1 KPa (paper)
Contact area	50 mm2 (film); 200 mm2 (paper) Note: Choose one of film and paper; non-standard can be customized
Power supply	AC 220V 50Hz / AC 120V 60 Hz
Dimensions	320mm (L)×400 mm (W)×420 mm (H)
Approximate net weight	33kg
