3500kg Scissor Type Hydraulic Ultra-Thin Scissors Car Lift with Lifting Height 1850mm

Product Description

Product Description
*New high-strength alloy booster arm, computer 3D dyamic simulation design, steadydescent under full load, 30CBL approach bridge can be used as extension plate, non splicedintegral bottom plate, solid steel X frame pneumatic mechanical safety lock.
*Hydraulic synchronization, dual hydraulic system, hydraulic lock and mechanical triplesafety device,automatic unlocking when descending.
* High speed fully automatic CNC lathe is used for processing oil cylinder components toensure excellent concentricity and smoothness, and the cylinder barrel is rolled withmirror surface.
*All imported seals and ball valves are equipped with hydraulic explosion-proof device5.
*Precise laser cutting technology, accurate size, smooth cut and high finish*Shot blasting surface treatment and high temperature spraying treatment ensuredurability.
*The supportable approach bridge can be applied to vehicles with longer wheelbase.
*All shafts are equipped with wear-resistant bearings.
*24V safety control circuit.
Detailed Photos
01 Anti slip approach board 02 Total four oil cylinders, Pneumatic 03 scissor arm is made of 25mm solid
safety lock gear manganese steel plate

04 booster arm 05 the connecting shaft is 4mm thick 06 Each shaft has oil filling hole,convenient for maintenance
and long service life Product Parameters

lifting capacity	3.5T
Lifting height	110-1850mm
Worktable length	1485-2040mm
Worktable width	660mm
Moto power	2.2kw
Power supply	220V/1PH, 380V/3PH

Certifications
Installation Instructions

Company Profile
Yantai Delilai Automobile Calibration Equipment Co.Ltd is a professional car testing manufacture and exporter.
Located in Yantai city,Shandong province with convenient transportation access .
We specialize in the desgin ,developement and production of auto repair and maintenance euipment,such as auto body frame machine,spray booth,auto lift,wheel balancer,kings of tools ,wheel alignment and related products .
All of our products comply with international quanlity standards and are greatly appreciated in a variety of different marktets throughout the world .We have ISO certificate ,CE certificate,SGS certificate etc.
So our well-euipped facilities and excellent quanlity control throughout all stages of production enables us to guarantee customer satisfaction.Now our products are widely used in various domestic and foreign repair shops and 4S vehicle maintenance stations. Besides we also have outstanding customer service. Hope you are the next cooperative partner with us.
FAQ
Q. What is your terms of payment?
A:T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q. How about your delivery time?
A:Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q: What is the regular color? May I order a special color I like?
A:The regular color is Blue, Orange, Red. Also we can do customize one for you.
Q: Can you supply OEM service?
A:Yes, we can, some customers prefer that use their Logo, their color. And we are glad to help them open their market.
Q: What is the warranty time?
A: Warranty time is 12 months. Parts have free replacement when damaged during this time.
