High Speed Servo Metal Wire Straightener Copper Steel Wire Straightening Cutting Machine

Product Description

High Speed Servo Metal Wire Straightener Copper Steel Wire Straightening Cutting Machine
Product Description
Brief description:
Human-machine-incorporated touchscreen control systems can save manpower for the customer. our company's main range of wire 1 mm to 5 mm can be customized, fastest of up to 150 meters per minute, available for copper, iron, aluminum, gold, silver, stainless steel, high carbon steel,l and plastic coated wire, and metal wire.
If you want faster speed, please contact customer service.
If you are concerned about the straightening effect, we can provide free proofing.
Questions to confirm before buying:
1. What is the specific material, such as iron wire, stainless steel wire, carbon steel, specifically medium-high and low carbon, or 304 201 206 and other materials.
2.What is the range of diameters?
3. do you have any specific requirements for straightness?
4. what is cutting length.
5. To the surface scratches to cut high or not? Can not have a little scratch or a little scratch is acceptable.

Product Parameters
1.Cutting wire diameter: 1-3MM
2.Cutting length range: more than 5mm
3.Feeding speed: adjustable speed 10-40 meters / minute
4.Tuning line material: ordinary carbon steel wire stainless steel wire, copper wire, nickel-manganese galvanized wire, etc.
5.Feeding frame: roller type
6.Wire feeding motor: servo 2.6KW + reducer
7.Straightening motor: ordinary motor 2.2KW
8.Cutting motor: servo motor 1KW + reducer
9.Number of wire feeding groups: 3+2 (5 pairs of wheels), OD 65MM
10.Control screen: touch screen
11.Number of straightening blocks: 6 (straightening shaft short)
If your wire diameter is not in this range, you can consult me, I will recommend the right machine for you according to your parameters.
Of course you can also download our catalog
1.fixed cutting straightening and cutting machine 2.Traceless guide wheel straightening and cutting machine
3.flying shear straightening and cutting machine 4.chasing straightening and cutting machine
Detailed Photos
1.English operation screen
2.Straightening method: 1. ritation straightening 2.straightening rollers
3.cut knift
4.servo motor cut
5.servo motor traction
