Serviceable Wood Log Debarker for Plywood Machine

Product Description

Product Description
1.High Efficiency and Accuracy: ZY-2900L-650 wood debarker machine is designed for high peeling rates of 100% and a low wood loss rate of 5%. This ensures efficient debarking with minimal waste, resulting in cost savings for our customers.
2.Customizable: The machine can be customized to meet specific customer requirements, including voltage (380v or as required).
3.It has a wide range of applications, and has good effects on popular wood species such as eucalyptus and poplar. It is an auxiliary equipment suitable for assembly line operations and automated production.

Detailed Photos
We provide on-site installation, commissioning, and training to ensure a smooth and successful integration of the machine into our customers' operations.

Product Parameters

1	Model	ZY-2900L-650
2	Double roller diameter	200 mm
3	single roller diameter	180 mm
4	Log length	2600 mm
5	Working diameter	100 mm to 650 mm
6	Speed	45 meters/min
7	Size of the blade	2900*160*13 mm
8	Double roller motor	11 KW, 2 units of 350# reducer
9	Single roller motor	11 KW, 2 units of 350# reducer
10	Hydraulic roller motor	5.5 KW
11	Hydraulic piston	2, diameter 80 mm, stroke 600 mm
12	Guide	2 units of Oil-immersed slide bar
13	Total power	49.5 KW
14	Overall size	5300*2150*1100 mm
15	Weight	6500 Kgs

Company Profile
Linyi Zhonghe Imp. & Exp. Co., Ltd. is professional in solutions of wood veneer production machine, plywood production machine, particle board machine, MDF board machine, saw mill machine, wood veneer, plywood, other related material and parts for wood processing industry, construction material and ma-chine, etc.
The detail business range is as following:
1-wood veneer production machine:
Log cutting machine, log debarker, core veneer peeling machine, face veneer peeling machine, wood veneer dryer, wood veneer clipper, wood veneer stacker, veneer tape, etc.
2-plywood production machine, film faced plywood machine:
Core veneer composer, putty spreader, veneer sanding machine, veneer jointer, glue powder, glue making machine, glue mixer, glue spreader, base plywood forming machine, cold press, hot press, bolier, Double Dimension saw, sanding machine, wood dust collector, stainless steel plates, cushion pads, etc.
3- Particle board machine and MDF board machine.
4-Saw mill machine: Vertical band saw, horizontal band saw, saw blade sharpener.

Packaging & Shipping
<1> Before Order ship, our engineer will test machine make sure it is in good condition.
<2> When loading, we will share pictures with you.
<3> After ship leaving, we will offer container and ship information for your reference.
<4> Offer all documents for you do custom clearance.

Certifications
Complete certification

Frequently Asked Questions
1. What products does your company offer?
Our company specializes in manufacturing and supplying equipment for the plywood and veneer industry. Our main products include:
• Wood Veneer Machines
• Plywood Making Machines
• Related Equipment and Accessories (both main machines and auxiliary equipment)
Additionally, we offer import and export agency services to help facilitate trade in the industry.
2. What is your delivery timeline for the products?
We provide customized delivery schedules based on specific product requirements and customer needs. The exact delivery time will depend on the type and quantity of equipment ordered.
3. What warranty do you offer on your products?
We offer a one-year warranty on major components of our machines. The warranty covers manufacturing defects and issues related to the main parts of the equipment. Specific warranty details will be provided along with the product's technical specifications.
4. Do you provide installation and after-sales services?
Yes, we offer comprehensive after-sales support:
• Online Support: We provide video tutorials, technical drawings, and installation manuals to assist with the setup and operation of our equipment.
• Offline Support: Our experienced technical staff can assist with on-site installation and commissioning, ensuring that the machines are properly set up and fully operational.
5. Which countries do you frequently export to?
We regularly export to various countries, including:
• Brazil (where we have local distributors)
• Argentina
• Paraguay
• Fiji
• Pakistan
• Bulgaria
• Ghana
We have experience working with these countries and can arrange shipping and handling in compliance with local regulations.
