Z/1800 Two Platen Injection Molding/Moulding Production Line

Z/1800 Two Platen Injection Molding/Moulding Production Line

US$10,000.00-400,000.00 1 Set (MOQ)

Basic Info.

Model NO.
Z/1800
Plastic Type
Thermoplastic, Tube Head Injection
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Distance Between Tie Bars(Width)(mm)
1650 mm
Ejector Force(Kn)
400 Kn
Warranty
1 Year
Open Stroke(mm)
2700 mm
Oiltank Cubage
2000 L
Screw Speed (Rpm)
0 - 95 Rpm, 95
Theoretical Shot Volume(Cm3)
7125 Cm3
Injection Rate (G/S)
1057 G/S
Injection Weight (G)
6484 G
Distance Between Tie Bars
1650*1550
Screw L/D Ratio
26, 26/24/22.3/20.8
Ejector Stroke
450 mm
Mold Height(mm)
750 - 1750 mm
Shot Volume (Theoretical)
7125/8362/9698 Cm3
Power (Kw)
94.9 Kw
Specification
New
Trademark
AOTAI
Origin
Zhejiang, China
Production Capacity
500 Set/Sets Per Year

Product Description

Z/1800 Two Platen Injection Molding/Moulding Production Line
Product Description
Specification
Machine model
Z/1800
Screw type
A
B
C
D
Screw diameter (mm)
120
130
140
150
Screw L/D ratio (L/D)
26
24
22.3
20.8
Shot volume (theoretical) (CM3)
7125
8362
9698
11133
Injection weight (PS)(g)
6484
7609
8825
10131
Pump max.pressure (Mpa)
21
Pump motor power (servo)(KW)
45+45+55+11
Number of heating area(Segment)
8+1
Machine dimension (L*W*H) (M)
13.3*4.2*4.9



1. What kind of plastic material can be used on this machine?
PP, PE, PS, ABS and other general material could be used on this machine.
If you have other special material such as PC, PMMA, PVC, please contact us for further information. 2. What is guarantee time for this machine?
12 months after installation or 18 months again B/L date.
3. What kind of shipping container for this machine?
Containere choose will depends on the different machine size . 20HQ,40HQ,40GP will suitable for different size machine.
4. How much is Engineer service charge?
We can send experienced technician to customer's country for guiding the installation and commission the machine, also train the
customer's employee. Customer need to afford technician visa charge, round trip air ticket expense, accommodation and
transportation in local. Also customer needs to pay USD 80 per days to technician as salary.
5. How long will be for installation and commission this machine?
If customer prepare all necessary thing such as power supply, water supply, hydraulic oil, plastic material, plastic mold,
installation and commission period will be within 7days including training customer's employee.
6. How many workers are needed to operate this machine?
One worker only.
7. What is the power consumption for this machine?
Power consumption is determined by the product. Different product requests different power consumption.
