Class 0 Industrial Energy-Efficient Oil-Free Scroll Air Compressor 1500W Emission Volume 0.17/0.12m3/Min
| US$450.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
V-15B
Lubrication Style
Oil-free
Cylinder Position
Horizontal
Weight
130
Maximum Pressure
0.8/1.0 MPa
Emission Volume
0.17/0.12 Cube/Min
Rated Power
1.5kw
Transport Package
Standard Export Package Carton/Wood
Specification
570*600*805(L*W*H)mm
Trademark
V&T
Origin
China
Product Description
Oil Free air -compressor Product DescriptionV&Toil-free scroll aircompressor is featured with stable performance, cleanness,nooil,low vibration and low noise.There is no need toaddany oil medium in the working process,and the compressed air conforms to the highest class zero oil-frees tandard of ISO-8573-1.In addition,it works continuously without any additional work with advantages offer accessories,simple structure,high reliability,andl ongservice life.When meeting customer demand forhigh-quality compressedair,weare constantly striving for higher product performance and better customer service.
Specification
| Model | V-15B | V-22B | V-37B | V-75B | V-110B | V-150B | V-185B | V-220B | V-260B | V-300B |
| Maximum Pressure Mpa | 0.8/1.0 | |||||||||
| Emission Volume m³/min | 0.17/0.12 | 0.24,/0.2 | 0.4/0.35 | 0.8/0.7 | 1.2/1.05 | 1.6/1.4 | 2/1.75 | 2.4/2.1 | 2.8/2.45 | 3.2/2.8 |
| Power Supply | 3 phase 380V50Hz | |||||||||
| Rated Power kW | 1.5 | 2.2 | 3.7 | 3.7*2 | 3.7*3 | 3.7*4 | 3.7*5 | 3.7*6 | 3.7*7 | 3.7*8 |
| Drive Mode | Belt Drive | |||||||||
| Controller type | Pressure switch/textedit controller/touch screen controller | |||||||||
| Tank Volum L | Additional external tank | |||||||||
| NoisedB(A) | 46±3 | 49±3 | 49±3 | 49±3 | 55±3 | 57±3 | 59±3 | 61±3 | 62±3 | 62±3 |
| Outlet Diameter Inch | R1/2 | R1/2 | R1/2 | R3/4 | R1 | R1 | R1 1/2 | R1 1/2 | R1 1/2 | R1 1/2 |
| Dimension L*W*H(mm) | 570*600*805 | 660*895 *945 | 740*1155*1670 | 1485*1150*1670 | ||||||
| Weight kg | 130 | 130 | 135 | 253 | 430 | 515 | 825 | 915 | 1005 | 1100 |
