Diesel 10HP Engine Powered Tiller
Basic Info.
Model NO.
1-gw-135
Application Field
Agriculture
Farming Policy
Dry Cultivating Machinery
Power Source
Gasoline
Operation
Soil Preparation Machinery, Continuous Running Operation
Traction Type
Traction
Drive Type
Gear Drive
Arbor Configuration
Vertical Shaft
Certification
CE
Color
Orange
Warranty
1 Year
Packing
Wooden Carton
Engine
Diesel or Gasoline
Blades
32PCS
Tranismission
Bear /Belt
Transport Package
Boxes
Specification
800*600*400
Trademark
GRANDER
Origin
China
HS Code
843229000
Production Capacity
1000sets/Month
Packaging & Delivery
Package Size
120.00cm * 80.00cm * 65.00cm
Package Gross Weight
140.000kg
Product Description
| 1WG4.0-FC SPECIFICATION | ||||
| | Item | Unit | Standard | |
| 1 | Engine | Model | / | 178F |
| Rated power | KW | 4 | ||
| Engine speed | r/min | 3600 | ||
| 2 | Power tiller | M.T | mm | 1210X690X1030 |
| Weight | kg | 115 | ||
| Displacement | ml | 406 | ||
| Working width | cm | 105 | ||
| Working depth | cm | ≥10 | ||
| Working speed | m/s | 0.1-0.3 | ||
| Hour production | hm²/h·m | ≥0.04 | ||
| Fuel consumption | kg/hm² | ≤25.0 | ||
| Drive way | / | Gear | ||
| Connection method | / | Direct coupled gearbox | ||
| 3 | Roll turning | Designed speed | r/min | First Gear:115;Second Gear:137 |
| Blade diameter | mm | 180 | ||
| Total number | Piece | 24 | ||
