Self-Propelled New Design Corn Picker Harvester Farm Machine with Chopping Corn Stalk Manufacturer Cheap Price

Product Description

Product Description
1.With 150 HP engine, fuel efficient and durable, powerful.
2.Use of famous tires, high wear resistance, better anti-sinking effect.
3.Increase the fuel tank, extend the working time.
4.Equipped with grain lifters to increase grain recovery
5.Increase the granary, reduce the number and time of unloading grain.
6.Install anti-entanglement plate to prevent debris from winding bearings.
7.Equipped with plate cutting table, optional combination cutting table tip. The cutting table can be harvested close to the ground.
The outside Angle is adjustable.It can realize the harvest of both row and non-row and lodging corn, and has a wide range of operations
8. Equipped with 4WD type, It not only ensures the power and passability, but also takes into account the fuel economy.
9.The front axle and gearbox are made by ourselves,many companies purchased it from our factory.

Product feature
1. strong power,flexible and efficient
With 150 horsepower engine, full of power; Short wheelbase design for front and rear wheels,Small turning radius,flexible steering, high operating efficiency
2. Harvest on the slope, handle it well
Four-wheel drive, short body, low center of gravity.The slope harvest is safer and more passable.
3. Stable, reliable and durable
The chassis is made of high-strength materials, Enhanced travel gearbox for higher reliability.
4. Easy to operate and comfortable to drive
Optimized control mechanism,steering wheel Angle is adjustable,Extended seat, driving experience is more comfortable.
Product Parameter

No.	Model	unit	4 YZ- 3 WF/3WA/3WQ	4 YZ- 3 WH
1	Number of rows	pcs	3	3
2	Power	KW/HP	110.3KW/150HP	110.3KW/150HP
3	Dimension	mm	6750*2740*3030	6750*2740*3030
4	Row width	mm	600	630
5	Driving model	/	4*4	4*4
6	Tyre size(F/R)	/	F:11.2-20 R:10.0/75- 15.3	F:11.2-20 R:10.0/75- 15.3
7	video surveillance	/	Y	Y
8	Axle base	mm	2500	2500
9	Wheel base(F/R)	mm	1820/1800	1820/1800
10	Transmission type	/	Mechnical+HST	Mechnical+HST
11	Weight	kg	5480	5750
12	Working efficiency	hm2/h	0.4~1.1	0.4~1.1
13	Grain Tank Capacity	m³	2m³	2.1m³
14	Qty of stripping rollers	pcs	16	16
15	Max. unloading height	mm	2350	2350
16	Engine structure type	/	In-line, water-cooled, supercharged intercooled, four-stroke, high pressure common rail
