Industrial Heavy-duty Vertical CNC Milling Machine X716 Series
| US$25,000.00-32,000.00 | 1 set (MOQ) |
Basic Info.
Model NO.
X716
Structure
Bed type
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Semiautomatic
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Worktable size
2500X600
X-axis travel
1800mm
Y-axis travel
700mm
T-slot
5/20/100
Spindle bore taper
ISO50
Net weight of machine
9000kg
Transport Package
Wooden Cases
Specification
11 kW
Trademark
Dalian ZT Machinery
Origin
China
HS Code
84595900
Production Capacity
200 Sets/Year
Product Description
Main Featureall guides are hardened, ground and supplied with oil by a central lubrication unit. Universal swivel head swings easily to a horizontal position. Servo-motor on all axes, infinitely variable feed, rapid feed, and speed control. Electronic hand-wheels on all axes. Ball screw drive on all axes Powerful main motor. Technical specifications:
| Specifications | Unit | X716 |
| Spindle hole taper | mm | 7:24 ISO50 |
| Spindle speed range | r/min | Variable 6-300,30-1500 |
| Distance between spindle axis and column guideway | mm | 8-660 |
| Distance between spindle nose and table surface(V) | mm | 0-700 |
| Distance between spindle axis and table surface(H) | mm | 8-660 |
| Table size | mm | 2500*600 |
| T slots | mm | 5/20/100 |
| Table travel-X | mm | 1800(2000) |
| Table travel-Y | mm | 700 |
| Table feed-X/Y | mm/min | 2.5-3000 |
| Table feed-Z | mm/min | 2.5-2500 |
| Table rapid feed X/Y/Z | mm/min | 6000/6000/3000 |
| Main motor power | kW | 11 |
| Torque of X/Y/Z axis AC servo motor | Nm | 18/23/18 |
| Cooling pump motor power | w | 90 |
| Overall size | mm | 4380*2520*2800 |
| Weight | kg | 9000 |
Standard accessories:
| NO. | Name | Specificcations | Q'ty. |
| 1 | Milling machine | X716 | 1 |
| 2 | Draw bar | 1 | |
| 3 | IS050 taper shell end mill holder | ISO50-Φ40 | 1 |
| 4 | 7: 24 middle cover | 7: 24 IS050/MS4 | 1 |
| 6 | Oil gun | 1 | |
| 6 | Foundation bolt | M16×450 | 6 |
| 7 | Allen wrench | 5,8,10 | 1 |
| 8 | Double-ended wrench | 27×30 | 1 |
| 9 | Double-ended wrench | 36×41 | 1 |
