High Voltage Industrial Explosion Proof Electrical 50Hz/60Hz Squirrel Cage Three Phase Asynchronous AC Induction Electric Motor

Product Description

High Voltage Industrial Explosion proof electrical 50Hz/60Hz squirrel cage Three phase asynchronous AC Induction Electric motor
The three-phase asynchronous motor uses three-phase symmetrical alternating current as the driving source. Through a specific mechanical structure and electromagnetic action principle, it converts electrical energy into mechanical energy to supply production machinery to achieve various movements. The basic working principle follows the law of electromagnetic induction. The magnetic field acts on the force of the current to make the motor rotate. The three-phase asynchronous motor can be divided into two parts: the stator and the rotor. Among them, the stator is the fixed part and the rotor is the rotating part.
According to the different rotor structures, three-phase asynchronous motors can be divided into cage type and winding type. Three-phase asynchronous motors are widely used in machinery, metallurgy, coal, petroleum, chemical industry and other industrial fields.
The main parameters of three-phase asynchronous motors include the following items:
(1) Rated power: Mechanical power output on the shaft under rated operating conditions, kW.
(2) Rated voltage: Line voltage applied to the stator winding under rated operating conditions, V or kV.
(3) Rated current: Line current of the stator winding when the motor outputs rated power under rated voltage, A.
(4) Rated speed: Speed of the motor at rated output power, rated voltage and rated frequency.
(5) Rated frequency: Standard frequency of the motor power supply voltage.
Three-phase asynchronous motors, especially squirrel-cage asynchronous motors, have the advantages of simple structure, durability, easy maintenance, easy starting and low cost. They are widely used in industrial systems as power sources for electric drive equipment, such as various machine tools, water pumps, fans, lifting equipment, processing equipment, etc.
Parameter:

Voltage:	380/400V/415V/660V/Customized
Rated Frequency:	50Hz/60Hz
Power Range:	0.75-1200kw
No. of Poles:	2.4.6.8.10.12 poles

Features:
High efficiency, Energy saving, Low noise, Little vibration, Reliable running
Application:
FAQ:
1.What information do you need to offer a quotation?
Voltage: V
Frequency: Hz
Power: Kw
2.Are you the manufacturer or trading company?
We are real manufacturer for motors,and we have been in this industry for more than 20 years.
3.Can we pay a visit to your factory?
Yes.We warmly welcome you to visit our factory.
4.What is the MOQ?
There is no MOQ.
1 set motor is ok.
5.Do you accept OEM orders?
Yes.Both OEM & ODM are available.
