Portable European Regulation Charging Gun, Mode 2, Adjustable Touch Current Type 2 European Standard 3.5kw Charging Gun

Product Description

Detailed Photos
Product Description
Product Features Description

Aesthetic Design, Handheld	Ergonomically designed for easy plugging and unplugging
Contact Head Design	Features a safe insulation design to prevent accidental direct contact with hands
Protective Performance	Superior, with a protection grade of IP65
Materials	Reliable materials featuring flame retardant, eco-friendly, wear-resistant, weather-resistant, impact-resistant, high oil-resistant, and UV-resistant properties

Electrical Performance Specifications

Rated Working Current	8/10/13/16A
Working Voltage	250V AC
Insulation Resistance	1000MΩ (DC500V)
Terminal Temperature Rise	<50K
Dielectric Strength	2000V
Contact Impedance	0.5mΩ Max

Mechanical Performance Specifications

Mechanical Lifetime	>10000 cycles under no load
Impact Strength	Can withstand a drop from 1 meter and being overrun by a 2-ton vehicle

Material Application Description

Casing Materials	Thermoplastic, Flame Retardant Grade UL94V-0
Probes	Copper alloy, silver-plated with thermoplastic on the tip

Ambient Temperature Range

Working Ambient Temperature	-30°C to +50°C

This product is a beautifully designed, portable charging gun that combines an ergonomic handheld design for easy plugging and unplugging. The contact head is safely insulated to prevent accidental electric shock. Boasting superior protective performance with an IP65 rating, the device is made from flame-retardant, eco-friendly, wear-resistant, and weather-resistant materials, ensuring high reliability and durability. In terms of electrical performance, the charging gun offers multiple rated working current options, operates at 250V AC, and features high insulation resistance and low contact impedance. It demonstrates excellent mechanical performance, withstanding multiple unloaded cycles and significant physical impact. Moreover, the casing is made from a high flame-retardant thermoplastic, and the probes are copper alloy with a silver plating, guaranteeing overall strength and longevity. Suitable for operating ambient temperature ranges from -30°C to +50°C, this product is an ideal charging solution for a variety of environments.
