YD-PL450C  Embossing Toilet Roll/Kitchen Towel/ Paper Making Line

YD-PL450C Embossing Toilet Roll/Kitchen Towel/ Paper Making Line

Negotiable 1 Piece (MOQ)

Basic Info.

Model NO.
YD-PL450C
Embossing Type
Full-Embossing
Embossing Roller
Steel Roller
Transport Package
Wooden Box Packing
Trademark
BAOSUO
Origin
No.20 Changjiang Load,Sanshan New Town Nanhai Fosh
HS Code
84411000

Product Description


YD-PL450C Embossing Toilet Roll/Kitchen Towel/ Paper Making Line
Product description:
REWINDING SYSTEM
Design speed 450 m/min
With core speed 400 m/min
Coreless speed 250 m/min
Jumbo roll width 1750 ~ 3600 mm
Jumbo roll diameter ≤φ2000 (To be order)
Jumbo roll core size φ76.2 mm (Other sizes are available)
Diamter of finishing log Φ60 ~ φ130mm
Core size φ35 ~ φ50 mm
Perforation 4 pieces spiral upper perforated
Rewinding way Non-stop
Control system PLC
Web tension system Encoder, PLC, Inverter
Machine speed 450 m/min
Backstand 1 ~ 3 Ply (To be confirmed by client, independent drive)
Option
Embossing unit Steel to rubber, point to point / nested / DECO embossing lamination system
Edge embossing unit Steel to steel
Printing unit 1 ~ 2 colors (Customers provides pattern)
ACCUMULATOR
Log diameter φ70 ~ φ135 mm
Storage 160 logs (Other size to be specified)
Speed 25 logs/min
LS200-4L LOG SAW
Log convey Adopt servo motor system control pusher log location
Design Speed 160 cuts/min
Number of line 2 ~ 4 lines
Grinding wheel system Pneumatic sharpen, the sharper parameter can be adjust in touch panel
Cutting mistake ±1 mm
Clamp size Φ70 ~ 135 mm (The standard size is Φ110 mm)
Dust suction system The unit can suction dust for grinding wheel
Cooling system Adopt the compressed air for cooling the grinding knife

Brief Introduction: Integrated with core and coreless rewinding, applied rewinding for several invention patents; Stable production speed: up to 400 m/min for rolls with core, 250 m/min for coreless; Complete warning system and powerful integrated control system, supports remote terminal connection and detection; Straight in machine web cutting, precise log diameter control system is accurate and easy operating; Patented vacuum suction technology for coreless roll rewinding to secure rewinding quality and production stability; Flexible and easy handling independent motor drive for each function unit; Rear doctor blade for web cutting and core gluing, perfect match product with embossing lamination; Equipped with edge embossing unit, 60 embossing wheel for regular web width; Applicable to various web tensions of different jumbo roll grades; PLC, large screen HMI, opto-mechatronics control technology, automatic web break detection, and accurate signal feedback. About us
Brand Number of Employees Annual sales Established in
BAOSUO
501-1000 People
More than US$50 Million
1989

Baosuo Enterprise., established in 1989, is a well-known corporation which specializes in machinery for tissue. We uphold the business strategy of basing on domestic market and going global, which helps to lay the foundation for building our global well-known brand. Our products include tissue making machines, tissue converting machines, tissue packing machines and electric intelligent systems. We are dedicated to providing the best tissue production turnkey solution and first-class service from design, manufacturing to installation.
Factory Exhibition Activities 1.The World Tissue Exhibition
2.Tissue World São Paulo
3.The 26th International Paper Industry Exhibition
FAQ 1.I am new in this business, what kind of information I need for start the project? Production requirement in details, such as products type, capacity, material size and so on.
2.I wan to produce toilet roll and kitchen towel, which machine is proper for me? We have different models based on capacity and specification, please provide us the detailed requirement, or get in contact with sales representatives for quotation.
3.What is the price of the machine? Machine price is based on confirmed machine model and specification, our sales representative will guide you the proper machine for you requirement, and offer quotation accordingly.
4.How can I get in contact with the sales representatives? Please contact with us via email, or leave message on website, our sales representatives will follow on your order on time.
5.How can I install the machine? We offer online installation instruction, or send technician for guiding installation and operation training based on requirement.
6.What about the after sale service and spare parts supply? Our after sales team will support your with on time suggestion and origin spare parts supply.
7.What is the guarantee time of the machine? Machine guarantee for one year after the acceptance.
