Basic Info.
Model NO.
Z series Lobe pump
Exhauster Method
Positive Displacement Pump
Work Function
Mainsuction Pump
Usage
High-Viscosity Liquid / Thick Liquid
Displacement
3L~200L/100rpm
Motor Speed Range
200~500rpm
Lobe Type
Single Impeller / Butter-Like Lobe / Tri-Impeller
Inlet / Outlet Port
1"~3"
Inlet / Outlet Port Connection
Thread / Clamp / Flange
Transport Package
Wooden / Nylon
Specification
CE, 3A, CCC, ISO, FDA, GMP
Production Capacity
2000PCS Every Season
Product Description
movable rotor pump for viscosity liquid rotary lobe pump Specification
Model | Z-3 | Z-6 | Z-8 | Z-12 | Z-20 | Z-30 |
Displacement L/100rpm | 3 | 6 | 8 | 12 | 20 | 30 |
Speed range rpm | 200~500 | 200~500 | 200~500 | 200~500 | 200~500 | 200~400 |
Corresponding flow L/H | 300-800 | 650-1600 | 850-2100 | 1300-3200 | 2100-5400 | 3200-6400 |
Moroe power Kw | 0.55 | 0.75 | 1.5 | 2.2 | 3 | 4 |
Orifice Size mm | Φ25×1.5 | Φ25×1.5 | Φ25×1.5 | Φ32×1.5 | Φ38×1.5 | Φ50.8×1.5 |
Size | L | 710 | 780 | 850 | 980 | 1000 | 1050 |
H | 290 | 390 | 400 | 450 | 450 | 480 |
H1 | 150 | 170 | 170 | 185 | 190 | 220 |
W | 150 | 190 | 190 | 220 | 250 | 270 |
W1 | 240 | 240 | 280 | 330 | 330 | 350 |
Tips | The specification listed here only for reference. |
High Viscosity Liquid Lobe Pump
Rotary Pumps are exceptionally versatile. While they are often used on thin liquids such as solvents and fuel oil, they excel at efficiently pumping thick liquids such as asphalt, chocolate, and adhesives. The useful viscosity range of an internal gear pump is from 1cPs to over 1,000,000cP.
In addition to their wide viscosity range, the pump has a wide temperature range as well, handling liquids up to 750ºF / 400ºC.
High Viscosity Liquid Lobe Pump
For more details information of our rotary pump, please get in touch with us directly:
High Viscosity Liquid Lobe Pump
offer movable rotor pump for viscosity liquid
