Supply Titanium Alloy Plate Gr5 Ti 6al 4V Gr7 Gr9 Gr23 Alloy Titanium Plate ASTM B265 High Temperature Resistant Titanium Plate

Product Description

Product Description
Product Parameters

Titanium Plate and sheet Type	Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate
Grade	ASME SB265,AMS 4911,AMS 4919,AMS 4914,ASTM F67,ASTM F136, MSRR, AMS, BS
Titanium Alloy Gr1 Gr2 Gr3 Gr4 Gr5 6Al4V Gr7 Gr9 Gr12 Gr23 Plate Length	1000mm-13000mm or as required
Gr1 Gr2 Gr3 Gr4 Gr5 6Al4V Gr7 Gr9 Gr12 Gr23 Titanium Plate Width	1000mm-1219mm-1500mm-1800mm-2000mm-2500mm or as required
UNS Plate Thickness	0.3 to 120mm or as required
ASTM B265 Titanium Alloy Gr1 Gr2 Gr3 Gr4 Gr5 6Al4V Gr7 Gr9 Gr12 Gr23 Plate Process	Hot/ Cold Rolled/forging
UNS Plate surface	No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B265 Titanium Alloy Gr1 Gr2 Gr3 Gr4 Gr5 6Al4V Gr7 Gr9 Gr12 Gr23 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc.
ASTM B265 Titanium Alloy Gr1 Gr2 Gr3 Gr4 Gr5 6Al4V Gr7 Gr9 Gr12 Gr23 Plate, Sheet and Strip	JIS: N0, N2, N1, NW2200, NW2201, NW4400, NW5500, NW6002, etc
	DIN:H-Ni99.96, H-Ni99.95, H-Ni99.92, H-Ni99.90, H-Ni99.5, H-Ni99, etc
Titanium Gr1 Gr2 Gr3 Gr4 Gr5 Sheet ASTM	ASTM B265
Titanium Gr1 Gr2 Gr3 Gr4 Gr5 Sheet AMS	AMS 4902
Tolerances of width and thickness	EN 10258 (formerly DIN 59381),EN 10151 ASTM B265 Titanium Alloy Gr1 Gr2 Gr3 Gr4 Gr5 6Al4V Gr7 Gr9 Gr12 Gr23 strip for springs,EN 10088 ASTM B265 Titanium Alloy Gr1 Gr2 Gr3 Gr4 Gr5 6Al4V Gr7 Gr9 Gr12 Gr23 strip (general)
Cp Gr1 Gr2 Gr3 Gr4 Gr5 Titanium Plate standards and approvals	EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 EN ISO 9445 ASTM A 480 ASTM A 959 ASME IID

Detailed Photos
At Jiangsu Daxun Alloy Co., Ltd., we produce top-tier titanium sheets in China, designed to cater to our customers' diverse and demanding requirements!Jiangsu Daxun is your trusted source for commercially pure titanium plates, offering Gr1, Gr2, Gr3, and Gr4 (UNS) with thicknesses from 0.5 mm to 120 mm. Known as the 'workhorse' of the titanium family, these grades provide an unbeatable combination of strength, ductility, and corrosion resistance for a wide range of industrial applications.
Gr1, Gr2, Gr3, and Gr4 titanium plates represent the pinnacle of commercially pure titanium. They offer an outstanding balance between strength and ductility, excellent impact strength, and are easily weldable. These plates excel in highly oxidizing environments, alkaline media, brine solutions, weakly reducing environments, and wet ***. Moreover, they boast superior resistance to seawater and salt solutions.
Gr5 grade5 Ti6al4v titanium plate is a superior titanium alloy containing 90% titanium, 6% aluminum, and 4% vanadium. This α-β titanium alloy features aluminum for stabilizing the α phase and vanadium for the β phase. Key benefits include excellent comprehensive and process performance, exceptional room temperature and high temperature strength, and remarkable resistance to fatigue and *** growth in seawater. It also offers excellent process plasticity and superplasticity, suitable for various processing methods and welding techniques.
Applications and standardsGr1, Gr2, Gr3, Gr4, and Gr5 Titanium Plates are lightweight yet incredibly strong, making them ideal for applications where weight is a critical factor. These plates are extensively used in military, medical, chemical equipment, and aerospace industries. Their strength and corrosion resistance make them perfect for marine, chemical processing, and desalination applications. Typical uses include oil and gas components, reaction and pressure vessels, piping systems, power, heat exchangers, linings, and flue gas desulfurization systems. Common Standards: ASTM B265, ASTM F67, AMS4911, AMS4928, AMS4943, AMS4944, AMS4945, AMS4967, AMS4972. Corrosion Resistance
Our Gr1, Gr2, Gr3, and Gr5 titanium plates offer exceptional resistance to seawater and marine atmospheric corrosion. While the four C.P. grades exhibit similar corrosion resistance, their mechanical properties differ based on oxygen and iron content. These grades resist wet chlorides, metal chlorides, chlorite and hypochlorite solutions, nitric and chromic acids, organic acids, and many industrial gases.
About the chemical composition of (Ti 6AL-4V) grade 5 titanium sheet

Chemical Composition:
Symbol	Element	Min %	Max %
Al	Aluminum	5.50%	6.75%
V	Vanadium	3.50%	4.50%
Fe	Iron		0.30%
O	Oxygen		0.20%
C	Carbon		0.08%
N	Nitrogen		0.05%
H	Hydrogen		0.01%
Y	Yttrium		0.01%
	Other, each		0.10%
	Other, total		0.40%
Ti	Titanium		Remainder

About the mechanical properties of (Ti 6AL-4V) grade 5 titanium sheet

Physical Properties	Metric	English	Comments
Density	4.43 g/cc	0.16 lb/in³
Mechanical Properties
Hardness, Brinell	334	334	Estimated from Rockwell C.
Hardness, Knoop	363	363	Estimated from Rockwell C.
Hardness, Rockwell C	36	36
Hardness, Vickers	349	349	Estimated from Rockwell C.
Tensile strength	min. 895MPa	129810 psi
Yield strength	min. 828MPa	120090 psi
Elongation at Break	min.10 %	10 %
Reduction of Area	min.25 %	25 %

About the chemical composition of grade 2 titanium sheet

Element	Weight %
C	≤0.08
O	≤0.25
N	≤0.03
H	≤0.015
Fe	≤0.30
*OEE	≤0.10
*OET	≤0.40
Ti	Remaining

About the mechanical properties of grade 2 titanium sheet

Alloy	UNS Designation	Spec.	Tensile Strength (min.)			Yield Strength 0.2% Offset (min.)			Elongation in 2 inches (min.)	Max Hardness	Modulus of Elasticity (x106 psi)	Mean Coefficient of Thermal Expansion IN./IN./°F x 10-6)	Thermal Conductivity (BTU-in/ft2-h-°F)
			psi	MPa	ksi	psi	MPa	ksi	%
Grade 2 Titanium	R50400	B338	50,000	-345	50	40,000-	(276-448)	40-65	20	-	16	5.1	144
						50,000

About the chemical composition of grade 1 titanium sheet

Element	Minimum (weight %)	Maximum (weight %)	Typical (weight %)
Fe		0.2
O		0.18
C		0.08
N		0.03
H		0.015
Ti	Balance

About the mechanical properties of grade 1 titanium sheet

Density
lb/in3	g/cm3
0.163	4.51
Tensile Strength
ksi	MPa
35 min	240 min
Yield Strength
ksi	MPa
20 min	138 min
Hardness
70 HRC max
Elongation
24% min

About the chemical composition of 3Al-2.5V titanium sheet ElementMinimum (weight %)Maximum (weight %)Typical (weight %)

Al	2.5	3.5
V	2.0	3.0
Fe		0.25
O		0.15
C		0.08
N		0.03
H		0.015
Ti	Balance

Packaging & Shipping
Company Profile
Introduction to Titanium Plate Manufacturing Process1. Cold-Rolled Titanium Plate: Our cold-rolled titanium plates undergo a meticulous plate rolling process with a final cold rolling step. These sheets are available in work-hardened or heat-treated conditions, ensuring superior quality and durability. Whether your needs require mechanical or chemical processing, we can customize further processing to meet your precise specifications. 2. Hot-Rolled Titanium Plate: Crafted through precise longitudinal or combined longitudinal and transverse rolling, our hot-rolled titanium plates range in thickness from 3.0mm to 155mm and are supplied in a heat-treated state. For optimal performance, creep flattening can be applied as an additional heat treatment to eliminate internal stresses and fulfill special flatness requirements. We also offer cut blanks, which are complex shaped parts tailored from parent metal, and further processing can be tailored to your unique demands.3. Forged Titanium Plate: Our forged titanium plates are produced by forging steel ingots on vertical hydraulic presses, followed by rolling, open die forging, or a combination of open die forging and rolling. These plates come in standard dimensions-up to 580 mm in thickness, 2000 mm in width, and 6000 mm in length. The exact dimensions and weight of the forged plates are tailored through mutual agreement between the manufacturer and the customer, ensuring precise customization to meet your specific needs.
Regardless of the titanium plate product you require, Daxun guarantees to fulfill your demands through our efficient and expert production processes.
We offer a diverse selection of alloys, widths, thicknesses, and lengths to precisely cater to your specific requirements. Certifications

CP GR1 Titanium plate PHYSICAL PROPERTIES
Physical Properties	Metric	English	Comments
Density	4.50 g/cc	0.163 lb/in³
a Lattice Constant	2.95 Å @Temperature 25.0 °C	2.95 Å @Temperature 77.0 °F	alpha phase
	3.29 Å @Temperature 900 °C	3.29 Å @Temperature 1650 °F	beta phase
c Lattice Constant	4.683 Å	4.683 Å @Temperature 77.0 °F	c/a = 1.587
Mechanical Properties	Metric	English	Comments
Hardness, Brinell	120	120	annealed
Hardness, Knoop	132	132	Estimated from Brinell.
Hardness, Rockwell B	70	70	annealed
Hardness, Vickers	122	122	Estimated from Brinell.
Tensile Strength	124 - 138 MPa @Temperature 427 °C	18000 - 20000 psi @Temperature 801 °F
	152 - 179 MPa @Temperature 316 °C	22000 - 26000 psi @Temperature 601 °F
	193 - 207 MPa @Temperature 204 °C	28000 - 30000 psi @Temperature 399 °F
Tensile Strength, Ultimate	240 MPa	34800 psi
Tensile Strength, Yield	170 - 310 MPa	24700 - 45000 psi
	76.0 - 90.0 MPa @Temperature 427 °C	11000 - 13100 psi @Temperature 801 °F	0.2% offset
	83.0 - 103 MPa @Temperature 316 °C	12000 - 14900 psi @Temperature 601 °F	0.2% offset
	110 - 124 MPa @Temperature 204 °C	16000 - 18000 psi @Temperature 399 °F	0.2% offset
Elongation at Break	24%	24%
	25 - 30 % @Temperature 427 °C	25 - 30 % @Temperature 801 °F
	30 - 35 % @Temperature 316 °C	30 - 35 % @Temperature 601 °F
	40 - 50 % @Temperature 204 °C	40 - 50 % @Temperature 399 °F
Reduction of Area	35%	35%
Tensile Modulus	103 GPa	14900 ksi
Compressive Modulus	110 GPa	16000 ksi
Poissons Ratio	0.37	0.37
Shear Modulus	45.0 GPa	6530 ksi
Charpy Impact	310 J	229 ft-lb	V-notch
Impact Test	136 J	100 ft-lb	Impact Strength
Coefficient of Friction, Dynamic	0.68	0.68	Ti sliding on Ti; 300 m/min
	0.8	0.8	Ti sliding on Ti; 40 m/min

CP GR2 Titanium plate PHYSICAL PROPERTIES
Density	Magnetic Permeability
0.163 lbs/in-3	Nonmagnetic
4.51 g/cm-3	Electrical Resistivity
Beta Transus (+/-25°F, +/--3.9°C)	21 µΩ/in
1680°F	0.53 µΩ/m
915°C	Elastic Modulus
Thermal Conductivity	15.2-17.4 Msi
12.60 BTU hr-1ft-1 °F-1	105-120 GPa
21.79 W m-1 °C-1	Typical values at room temperature of about 68-78°F (20-25°C)

GR5 TI6AL4V Titanium plate PHYSICAL PROPERTIES
Physical Properties	Metric	English	Comments
Density	4.43 g/cc	0.16 lb/in³
Mechanical Properties
Hardness, Brinell	334	334	Estimated from Rockwell C.
Hardness, Knoop	363	363	Estimated from Rockwell C.
Hardness, Rockwell C	36	36
Hardness, Vickers	349	349	Estimated from Rockwell C.
Tensile strength	min. 895MPa	129810 psi
Yield strength	min. 828MPa	120090 psi
Elongation at Break	min.10 %	10 %
Reduction of Area	min.25 %	25 %
Modulus of Elasticity	113.8 GPa	16500 ksi
Compressive Yield Strength	970 MPa	141000 psi
Notched Tensile Strength	1450 MPa	210000 psi	Kt (stress concentration factor) = 6.7
Ultimate Bearing Strength	1860 MPa	270000 psi	e/D = 2
Bearing Yield Strength	1480 MPa	215000 psi	e/D = 2
Poisson's Ratio	0.342	0.342
Charpy Impact	17 J	12.5 ft-lb	V-notch
Fatigue Strength	240 MPa	34800 psi	at 1E+7 cycles. Kt (stress concentration factor) = 3.3
Fatigue Strength	510 MPa	74000 psi	Unnotched 10,000,000 Cycles
Fracture Toughness	75 MPa-m½	68.3 ksi-in½
Shear Modulus	44 GPa	6380 ksi
Shear Strength	550 MPa	79800 psi	Ultimate shear strength
Electrical Properties
Electrical Resistivity	0.000178 ohm-cm	0.000178 ohm-cm
Magnetic Permeability	1.00005	1.00005	at 1.6kA/m
Magnetic Susceptibility	3.30E-06	3.30E-06	cgs/g
Thermal Properties
CTE, linear 20°C	8.6 µm/m-°C	4.78 µin/in-°F	20-100ºC
CTE, linear 250°C	9.2 µm/m-°C	5.11 µin/in-°F	Average over the range 20-315ºC
CTE, linear 500°C	9.7 µm/m-°C	5.39 µin/in-°F	Average over the range 20-650ºC
Specific Heat Capacity	0.5263 J/g-°C	0.126 BTU/lb-°F
Thermal Conductivity	6.7 W/m-K	46.5 BTU-in/hr-ft²-°F
Melting Point	1604 - 1660 °C	2920 - 3020 °F
Solidus	1604 °C	2920 °F
Liquidus	1660 °C	3020 °F
Beta Transus	980 °C	1800 °F

A global leader in high-performance Ti-6Al-4V titanium plate alloy Grade 5 titanium plate manufacturing services.Grade 5DAXUN is a premier Ti 6AL 4V-Grade 5-TC4 UNS R56400 Alloy Titanium Plate manufacturer and supplier based in China! We strive to create the world's finest high-performance titanium alloy plates. With rapid worldwide delivery, we offer ASTM B265 Grade 2 and Grade 5 Titanium Plates. DAXUN's inventory includes Grade 5 alloy titanium plates (UNS R56400) with thicknesses from 0.5mm to 300mm (0.5mm-6.0mm cold rolled, 6.0-50mm hot rolled, and 50mm+ forged). Grade 5 titanium plate (Ti-6Al-4V) is the cornerstone of titanium alloys, known for its superior strength, ductility, high temperature resistance, and excellent corrosion resistance, making it a favorite in both general and military industries. Compliant with: ASTM, ASME, AMS, GB, GJB, MIL, JIS, EN, etc.
Ti-6Al-4V Grade 5 titanium plate is predominantly used in aerospace, military, power industries, vehicle armor, rocket precision guidance parts, and the marine sector.
Grade 1
Today, DAXUN Alloys stands as a leading global producer and supplier of top-quality Grade 1 titanium plates.
Pure Grade 1 titanium plate boasts exceptional ductility and cold formability, making it ideal for deep drawing applications. Grade 1 titanium is celebrated for its outstanding general and seawater corrosion resistance, as well as its resilience to oxidizing, neutral, and mildly reducing environments, including chlorides. Titanium's low density (roughly half that of nickel-based alloys), high strength-to-weight ratio, and corrosion resistance render it perfect for harsh chemical conditions. Commercially pure Grade 1 titanium is the softest and most ductile variant, offering superior cold formability, weldability, and impact hardness.
ASTM B265 Titanium Gr 1 Plate Producers, Titanium Gr 1 Sheets, Titanium Gr 1 Finished Plates, ASTM B265 Titanium Grade 1 Coil Suppliers, Pure Titanium Titanium Gr 1 Hot Rolled Plates, Titanium Gr 1 Cold Rolled Plates, Titanium ASTM B265 Gr 1 Sheets, Gr 1 Titanium Patterned Plates Dealers, Titanium Gr 1 Perforated Plates, Titanium Grade 1 Sheets and Plates Manufacturers in China.
Grade 2
DAXUN manufactures and stocks commercially pure titanium plates Grade 2 (UNS R50400) in thicknesses from 0.5mm to 120mm. Grade 2 Titanium Plate (UNS R50400) is the mainstay of commercially pure titanium, combining high strength, ductility, and exceptional corrosion resistance for various industrial applications.
Grade 2 Titanium Plate is a commercially pure titanium plate offering an excellent balance between strength and ductility. It possesses good impact strength and weldability, with significant corrosion resistance in highly oxidizing environments, alkaline media, brine solutions, weakly reducing environments, and wet ***. It also provides superior resistance to seawater and salt solutions.
Titanium's low density, high strength-to-weight ratio, and incredible corrosion resistance make it an ideal material for a wide array of applications. It exhibits excellent resistance to stress corrosion cracking, pitting, and crevice corrosion in chloride solutions below 70°C. With a melting point of 1660°C, Grade 2 Titanium Plate is the preferred alloy for most industrial applications requiring substantial ductility and corrosion resistance.
DAXUN is a metal industry expert dedicated to both small and large titanium plate projects. As your reference point and long-term partner, DAXUN is poised to supply your business with titanium plates and any necessary technical support. Consider DAXUN not only as your supplier of industrial pure titanium plates and titanium alloy plates but also as your strategic partner, ready to assist you in overcoming any challenges and meeting your objectives, ultimately driving the success of your projects.
At Jiangsu Daxun Alloy Co., Ltd., our dedicated service center in China boasts a comprehensive inventory of Premium Titanium Alloy Plate Gr23 Ti-6al-4V High Quality ASTM B265 products, primed for rapid order fulfillment. Leveraging advanced techniques such as water jet cutting and precision plate nesting, we deliver unparalleled value to our esteemed customers, significantly reducing both their time and operational costs.
Relentless investment in Jiangsu Daxun Alloy Co., Ltd.'s state-of-the-art production facilities, coupled with strategic capacity agreements with our esteemed partners, positions us at the pinnacle of titanium plate quality. This commitment ensures that DAXUN remains a leader in excellence, now and for the foreseeable future.
Reach out to Jiangsu Daxun Alloy Co., Ltd. today to receive the most competitive pricing and comprehensive technical details on our Premium Titanium Alloy Plate Gr23 Ti-6al-4V High Quality ASTM B265. Experience unmatched quality and service with DAXUN.
