Food Industrial Fruit Dryer Digital Control Garlic Grape Drying Machine Seafood Potato Dehydration Hot Air Dryer Machinery Raisins Yam Vegetable Dehydrator

Product Description

Fruits Vegetable Food Dryer Digital Control Garlic Grape Drying Machine Seafood Potato Dehydrator Hot Air Dryer Machinery Raisins Yam Jicama Dehydrator

The energy saving heat pump dryer machine is using inverse Carnot cycle principle and driven by a small amount of electric energy.
1) The refrigerant (Freon) is pressurized by the compressor to become a high temperature and high pressure gas (temperature up to 100ºC) before it enters the heat exchanger (condenser);
2) The refrigerant gas is condensed and liquefied in the condenser to release high temperature heat energy,which will be transferred into the drying chamber by circulating fan to heat the air there.
3) The water in the materials are vaporized through the form of hot air, and the evaporated water steam is discharged away by the dehumidification system to achieve the purpose of drying the materials in the drying chamber.
4) After condensation and heat release,the refrigerant is changed into a low temperature and low pressure liquid through the expansion valve.
5) The liquid refrigerant will continuously absorb the low heat energy of the surrounding air and quickly evaporate into a gas state when it enters the evaporator due to the sudden reduction of the pressure;
6) The refrigerant that absorbs a certain amount of energy flows back to the compressor and the next cycle begins. In this way, the refrigerant continuously circulates the heat energy in the air to the drying chamber to heat the air.
Main Components of Heat Pump Dryer
Advantages of Closed Loop Heat Pump Dryers 1) PLC and touch screen fully automatic control mode;The operation is automatically completed by a microcomputer,which can be controlled remotely.
2) By using the proprietary technology of regenerative circulation heat pump dehumidification method, our dryers can save operating cost and save more than 50% energy compared with traditional drying mode.
3) The integrated design of the indoor and outdoor can preheat the fresh air; It can also reduce the impact on the dyring material when the fresh air enters the drying chamber on the materials.
4) Dedicated compressor and thermal expansion valve throttling technology to ensure the stability of various working conditions. 5) The dryer has a comprehensive protection function (high pressure,low pressure,exhaust,etc.) fault protection function to ensure the safe operation of the equipment.
6) Drying materials are not affected by the external environment temperature,and the wide temperature range makes it easier to use in winter or in cold areas.
7) It adopts closed-type condensation and dehumidification technology for drying,which can collect condensed water and dry materials with volatile components that have recycling value and dissolve in water.
8) The dryers adopt cold-air dehumidification and hot-air drying methods,which is widely used for drying various fruits,vegetables,meat,seafood,nuts,leaves,agricultural products,etc.
Intelligent Touch Screen
Technical Parameters of Heat Pump Dryer

Model number	DY-18YL/YH(6HP)	DY-36YL/YH(12HP)	DY-45YL/YH(15HP)	DY-60YL/YH(20HP)	DY-75YL/YH(25HP)
Heating Capacity	18kw	36kw	45kw	60kw	75kw
Moisture Removal	18L/H	36L/H	45L/H	60L/H	75L/H
Refrigerant Type	R22/R134a	R22/R134a	R22/R134a	R22/R134a	R22/R134a
Rated Power	5.2kw	11.5kw	15.4kw	18.4kw	22.8kw
Rated Current	9.8A	21.6A	28.9A	34.6A	42.9A
Maximum Power	15.2kw	21.5kw	25.4kw	38.4kw	42.8kw
Maximum Current	28.6A	40.4A	47.7A	72.2A	80.5A
Voltage/Frequency	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ
Protection Against Electric Shock	Class I	Class I	Class I	Class I	Class I
Drying Chamber Temperature	35~70ºC	35~70ºC	35~70ºC	35~70ºC	35~70ºC
Ambient Temperature	5~45ºC	5~45ºC	5~45ºC	5~45ºC	5~45ºC
Maximum Exhaust Pressure	0.7/2.8MPa	0.7/2.8MPa	0.7/2.8MPa	0.7/2.8MPa	0.7/2.8MPa
Noise	≤53dB	≤53dB	≤53dB	≤53dB	≤53dB
Standard Air volume	7200m³/H	14400m³/H	18000m³/H	24000m³/H	28800m³/H
Net Weight	200kg	300kg	400kg	500kg	600kg
Dimensions(L*W*H)	1600*1100*1300mm	2000*1400*1500mm	2000*1400*1500mm	2300*1800*1600mm	2300*1800*1600mm

Heat Pump Dryers Application
85% of Mature Materials Drying Solutions
1) Vegetables: like radish, lettuce, pumpkin, carrots, spinach, cassava,etc.
2) Fruits:apples,mango,pitaya,peach,apricot,plum,raisins,wolfberry,jujube, lychee,longan,walnut,strawberry,cherry,pineapple,kiwi,small tomato,etc.
3) Meat: preserved meat,sausage,steak,duck,beef,mutton,chicken,pork,sauce duck,meat products.
4) Seafood: shrimp,fish,shellfish, hippocampus,squid,cuttlefish,hairtail,carp, crucian carp, sardine,cod, etc.
5) Crops: Rice noodles, noodles, grains, tremella, bean curd, corn, wheat, soybeans, soya beans, mung beans, lentils, soybeans.
6) Flowers and leaves: Rose, Chrysanthemum, osmanthus, honeysuckle, Chinese rose, jasmine, lily, Panax notoginseng, Dendrobium, lotus, okra flowers
7) Rhizomes: Sanqi, dendrobium, maca, gastrodia elata, pueraria, American ginseng, angelica, ganoderma lucidum, potatoes, turmeric, peanuts, yam, taro.
8) Chinese herbs:ginseng,Rhizoma Gastrodiae,Momordica grosvenori,glossy ganoderma,etc.
9) Industrial: Plate incense,wire incense,mosquito coil incense,Buddha incense,printing, rubber, gypsum,leather,ceramic,cloth,paper tube, sludge,ripening room 10. Wood: Yellow pear, rosewood, bright red acid branch, fir, eucalyptus, red pine, white pine, birch, Paulownia,lime, water willow,etc.
Hundreds of drying projects experience; Introduced advanced manufacturing technology.
Zero pollution,low energy consumption,environmental protection,energy saving heat pump dryers.
Our Services
A. Order Process
INQUIRY → QUOTATION → AGREEMENT → ORDER CONFIRM → PROFORMA INOICE OR CONTRACT → DOWN PAYMENT → PRODUCTION → BALANCE PAYMENT → DELIVERY → DOCUMENTS DESPATCH → GOODS COLLECTION → INSTALLATION → OPERATION → FEEDBACK
B. OEM & ODM are welcome;

C. Technical support for your installation,operation and maintenance.

D. One year's warranty, and you can pay for extended warranty.All life time technical support.

E. Spare parts and technical support at most economic prices after the warranty.
