Multi-Purpose Combination Machine with Turning, Milling, Drilling and Threading (KY450/KY700)
| US$1,088.00-1,395.00 | 3 Sets (MOQ) |
Basic Info.
Model NO.
KY450/KY700
Automation
Manual
Suitable for
Plastic, Rubber, Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
Spindle Taper
Mt3
Spindle Stroke
80mm
Color
Red
Warranty
1 Year
Height of Center
125mm
Motor
0.75kw
Motor Poser
550W
Spindle Speed
400-1640rpm
Max.Length Cutting
420(660)mm
Max.Swing Over Bed
250mm
Transport Package
Plywood Case
Specification
precision
Trademark
KY
Origin
China(Mainland)
Production Capacity
150-200 Sets /Month
Product Description
| Specification | |
| Model No. | KY450/KY700 |
| Height of center | 125mm |
| Max.distance between two centers | 450(700)mm |
| Max.length cutting | 420(660)mm |
| Max.swing over bed | 250mm |
| Max.swing over carriage | 130mm |
| Taper of spindle nose | MT4/27mm |
| Spindle speed range | 115-1620rpm |
| Matric thread cutting | 0.2-3.5mm(20 kinds) |
| Inch thread cutting | 8-56/1(20 kinds) |
| Moulder thread cutting | 0.1-1.25mm(10kinds) |
| Range of longitudinal feed | 0.05-0.1mm |
| Max.round angle of tool post | 45° |
| Max.travel of tool post | 70mm |
| Taper of tailstock sleeve | MT2 |
| Motor | 0.75kw |
| Drilling/Milling | |
| Spindle taper | MT3 |
| Spindle stroke | 80mm |
| Spindle nose to table | 160mm |
| Milling table size | 215*150mm |
| Spindle speed | 400-1640rpm |
| Motor poser | 550W |
| Standard accessories | |
| Splash guard | 1 pc |
| Chip tray | 1 pc |
| Drawbar | 1 pc |
| Arbor | 1 pc |
| Toolbox & tools | 1 set |
| Optional accessories | |
| 4-jaw chuck | 1 set |
| Backplate | 1 pc |
| Follow rest | 1 pc |
| Steady rest | 1 pc |
| Face plate | 1 pc |
| Collet chuck | 1 set |
| Turning tools | 1 pc |
Economical , widely useful hobby lathe. V-way bed is precision ground. Spindle is supported by precision tapered bearing Gear head enables to quickly change speeds. Power longitudinal feed allows threading. Adjustable gids for slidways. Change gears has large feed and threading functions. Tailstock may be offset for turning tapers. Mill head can be tilt ±90°.
