High Shear Emulsifying Mixing Tank Machine for Food/Beverage
| US$10,000.00 | 1 set (MOQ) |
Basic Info.
Model NO.
MG-170
Process
Electric Heating
Automatic Grade
Semi-Automatic
Application
Mixing Equipment for Dairy, Drinks, Food
Customized
Customized
Material
Stainless Steel 304 / SUS316L
Stirrer Type
High Speed Homogenizer
Usage
Mixing Liquid Detergent
Transport Package
Wooden Cases
Specification
CE
Trademark
SIGNUM
Origin
China
HS Code
84382000
Production Capacity
100 Sets/Year
Product Description
Stainless Steel Mixing Emulsification TankThis equipment is suitable to blend the dairy products,beverages,fruit juices etc with high-speed.
Tank part parameters:
| Effective volume | 300L |
| Design temperature | ≤100 °C |
| Working temperature | ≤90 °C |
| Design pressure | atmospheric pressure |
| Working pressure | atmospheric pressure |
| Tank material | SS316L material in contact with material, SS304 material in other parts |
| Tank structure | vertical, single-layer structure, upper and lower standard elliptical heads |
| Tank wall thickness | 4-6mm |
| Surface treatment | the inner surface is mirror-polished, the outer surface is polished on the upper and lower heads, and the barrel is brushed; |
| Support form | leg-type floor installation, the bottom of the tank valve outlet is about 300mm from the ground |
Other Parts:
| Motor reducer | double stirring, horizontal gear reducer |
| Motor power | 1.5kw |
| Output | speed 60r/min |
| Voltage | 380V / three-phase / 50HZ |
| Stirrer | anchor stirrer, stainless steel SS316L material, make the material mix evenly, the mixing system adopts detachable structure design, easy to overhaul |
| Reducer frame | SS304 material homemade frame |
| Emulsifier | 4kw three-stage high shear emulsifier, material contact part SS316L material |
| Pipe section | SS316L material |
Product Show:
Our Service: One year guarantee Provide the permanent components, technology support, quick response to after-sales service
