Liugong High Quality 20ton Crawler Excavator Medium Excavator 922e with 1cbm Bucket

Product Description

Product Description
922E Crawler Excavator
* Unmatched performance driven by the best Engine enhances torque output with more power and breakout force at lower engine speeds.
* Options for auxiliary hydraulic piping include bidirectional variable high flow line, an additional line for rotating attachments and also a single acting line. The quick coupler further ensures you get the most out of your machine by easily switching between a wide range of attachments to suit any application.* Ergonomically designed cab for LiuGong E series excavator, with great visibility, expansive room, new multi-function LCD monitor, automatic air conditioner, large storage space, provide most comfortable working environment
* Hydraulic request signals detect activity, decreasing and increasing engine speed as required. Power is supplied only as needed, achieving optimum fuel efficiency.
HIGHEST SAFETY STANDARDS
The machine meets European Certifying ROPS cab compliant with ISO 12117-2:2008. Falling Object Protection System (FOPS) is optional. An optional rearview camera gives an exceptionally clear view of the rear work zone on the wide-screen monitor.
ENHANCED VERSATILITY
Additional spool in the control valve and the space for PTO pump on the main pump allow for the easy installation of attachments lines.
OPERATOR COMFORT
Ergonomically designed cab for Liugong E series excavator, with great visibility, expansive leg room, new multi-function LCD monitor, automatic air conditioner, large storage space, provide the most comfortable working environment.
EFFICIENT AND ENVIRONMENTAL FRIENDLY
Equipped with a fuel efficient world-class B5.9 engine, compliant with EU stage II/EPA Tier 2, and the advanced IPC(Intelligent Power Control) system balances the engine and hydraulic pump to achieve high efficiency and low fuel consumption.
ALWAYS RELIABLE
Major parts are all from world-class suppliers. The improved boom and arm, reinforced undercarriage is designed to withstand some of the toughest working environments.
Product Parameters

Operating weight	22000 kg
Engine power	112 kW (150 hp) @ 1950 rpm
Bucket capacity	0.9 / 0.95 / 1.0 / 1.1 / 1.2 m³
Maximum travel speed (High)	5.7 km/h
Maximum travel speed (Low)	3.3 km/h
Maximum swing speed	12.5 rpm
Arm breakout force	97 kN
Arm breakout force Power boost	105 kN
Bucket breakout force	140 kN
Bucket breakout force Power boost	152.5 kN
Shipping length	9540 mm
Shipping width	2990 mm
Shipping height	3140 mm
Track shoe width (std)	600 mm
Boom	5710 mm
Arm	2915 mm
Digging reach	9870 mm
Digging reach on ground	9685 mm
Digging depth	6562 mm
Vertical wall digging depth	5080 mm
Cutting height	9945 mm
Dumping height	7170 mm
Minimum front swing radius	3090 mm
Model	6BTAA5.9-C150
Emission	EPA Tier 2 / EU Stage II
System maximum flow	2×224 L/min (2x59 gal/min)
System pressure	34.3 MPa

Detailed Photos
COMPLETE CUSTOMER CARE
Inspection parts, filters, and water separator are conveniently located.
