Full Automatic Drilling Machine Angle Steel Punching Machine
Basic Info.
Model NO.
40
Structure
Bench Drilling Machine
Layout
Vertical
Controlling Mode
CNC
Number of Shaft
3
Hole Diameter
<50mm
Automatic Grade
Automatic
Precision
High Precision
Certification
CE
Condition
New
Weight
1500kg
Maximum Workpiece Length
6000mm
Maximum Length of One Feeding
1500mm
Power (Kw)
5.2
Transport Package
Wooden Box
Specification
3600*1200*1850mm
Trademark
soar
Origin
China
Product Description
1. Touch Screen settings, CNC control system, precise servo motor positioning, module sto-rage memory function.2. Structure: Steel plate welded structure3. Mould replacement: change the dies easily without adjusting the dies to reduce mould da-
mage rate , Skilled workers can changethe mould within 10 minutes.4. Punching Category: (1).single hole punching; (2).double hole punching; (3).Isometric hole
punching; (4). none- Isometric holepunching,(5) rotary punching(only for round pipe).(6) punch from upward side and horizontal
two sides5. Hydraulic ,pneumatic and Servo System.6. Step-less operation adjustment, hydraulic loops designed with zero load, combined with e-
x
tremely low frequency oil pump motor,effectively reduced noise, increased motor efficiency and service duration.7. double punching heads machine can punch hole with two hydraulic cylinders, or only one
cylinder punch separately
| Device model | ZKJ-30 | ZKJ-40 | ZKJ-50 |
| Maximum round tube specification | Ф50(copper aluminum steel) | Ф80(copper aluminum steel) | Ф100(copper aluminum steel) |
| Maximum square tube specification | 50×50 | 80×80 | 100×100 |
| Maximum processing wall thickness | 4mm(SS) | 8mm(SS) | 10mm(SS) |
| Maximum processing wall thickness | 4mm(copper aluminum steel) | 8mm(copper aluminum steel) | 10mm(copper aluminum steel) |
| Punching specifications | Ф3.5~Ф10mm | Ф3.5~Ф30mm | Ф3.5~Ф40mm |
| Maximum length of one feeding | 1500mm | 1500mm | 1500mm |
| Number of holes processed continuously | No limited | No limited | No limited |
| Maximum workpiece length | 6000mm | 6000mm | 6000mm |
| Processing efficiency | 6-8 S/hole | 8-10 S/hole | 10-15 S/hole |
| Feeding speed | 800mm/S | 800mm/S | 800mm/S |
