460*200 Transtar CSD250m High Precision 2 Axis Molding Artificial Manual High Speed Handwheel Feed Surface Grinder Grinding Machine
| US$7,100.00-7,500.00 | 1 set (MOQ) |
Basic Info.
Model NO.
CSD-250M
Type
Surface Grinding Machine
Processing Object
Planar Mill
Abrasives
Grinding Wheel
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
High Precision
Condition
New
Table Dimensions
460X200 mm
Maximum Left-Right Movement
260 mm
Mechanical Height
1775 mm
Occupied Area
1800X1400 mm
Transport Package
Customizable
Specification
Customizable
Trademark
TRANSTAR
Origin
China
Product Description
Product DescriptionPRODUCT SPECIFICATIONS
| Mountings | Specifications | Unit | CSD-250M | |
| Ability | Table Dimensions | mm | 460×200 | |
| Maximum forward and backward movement | mm | 540 | ||
| Maximum left-right movement | mm | 260 | ||
| Distance between spindle center and work surface | mm | 470 | ||
| Maximum bearing weight of working table | kgs | 100 | ||
| Work Table | Table T-slots | mm×N | 14×1 | |
| Table speed | m/min | 7-25 | ||
| Front and rear handwheel feed | a check | mm | 0.02 | |
| a round | mm | 4 | ||
| Auto-supplying from front to back | mm | / | ||
| High speed moving from frong toback | 50HZ | m/min | / | |
| 60HZ | m/min | / | ||
| Grinding Wheel | Grinding Wheel Size | mm | Φ205×6-20×31.75 | |
| Speed of mainshaft | 50HZ | R.P.M | 2850 | |
| 60HZ | R.P.M | 3360 | ||
| Upper and lower mechanism | Up& down handwheel feed | a check | mm | 0.01 |
| a turing round | mm | 2 | ||
| Auto-supplying volumn | mm | / | ||
| High-speed mouing dimension from up to down | mm/min | / | ||
| Motor | Spindle motor | H×P | 2×2 | |
| Drive motor up and down | H×P | / | ||
| Drive motor up and down | H×P | / | ||
| Vacuum motor | H×P | 3/4×2 | ||
| Dust catching motor | H×P | 1/8×2 | ||
| Back and front driving motor | H×P | / | ||
| Machine Size | Mechanical height | mm | 1775 | |
| Occupied area | mm | 1800×1400 | ||
| Net weight | kgs | 1100 | ||
| Gross Weight | kgs | 1300 | ||
