HDPE Extruder Machine / Plastic Granules Machine

Product Description

we supplied all kinds of used/second hand/old rubber processing machines including tire machines,conveyor belt machins,rubber track machines,etc. Advertising PVC banner flex sheet production line machine/ cloth printing fabric making machine
Note: We can design the different size of machine according to the requests for products.



1, Other Name:

PVC banner flex making machine

SY-5F 610*1830mm PVC film making machine for banner flex

pvc banner flex making machine

PVC banner flex making machinery, PVC flex banner production line

Plastic film recycling line/PP PE film recycling line/pvc banner flex making machine

3.2M 0.25-2MM PVC banner flex making machine

pvc flex banner making machine

PVC flex banner sheet making machine

Advertising PVC banner flex sheet production line machine

PVC flex banner sheet production line making machine

pvc banner flex making machine/flex background banner,pvc banner flex making machine


2, Description:

This equipment adopts the 3-in -one structure of film--glass fiber mesh cloth--film or 2 in one with films and glass fiber mesh cloth structure, which can be made into flex banner , inkjet Print, AD print etc,which can be used everywhere for public projects, such as the exhibition hall, museum, library, gymnasium, art, display hall, opera, university, middle school; besides, it can also be used for AD sales. For more important, its function can appear for the public lighting system, such as the square, parks, construction display project for the airport and railway stations; Additionally, it can beautify the whole wall, which make people feel warm and beautiful, such as the hotels, canteens, teashops, sack houses, bars, balls, gym etc.



3, Advantages:

1. With equal thickness, having good ink absorption and strong color appearance

2. High density for the connection of PVC and mesh cloth.

3. Heating by mirror rollers

4. No need to paste glue, compound with hot pressing.

5. With automatic winder, easy for operating.

6.Correct temperature control, equal control for tension.

7. All heating rollers has been process precisely, with high precision and good balance for the concentricity and coaxality.
8. With good temperature protection for the heating rollers, with low loss of power.

9. Main electrical parts adopt famous foreign brand, with good stability and credibility ,

10. This equipments have the advantages of big capacity, high efficacy, stable quality, easy operation and etc, it is the best choice for Ad customers.

4, Parameters:

1, Available width 3200MM
2, Diameter for mail roller 1000MM
3, Length of roller face 3600mm
4, Working speed 5~15M/min
5, Heating method Hot oil conduct heating
6, Power for hot stove 1000000 Kal/h
7, Power for electricity About 20KVA

Parameter Product Type	XJ-65	XJ-85	XJ-115	XJ-150	XJ-200	XJ-250
Screw Thread Type	Dual Head Same	Dual Head Same	Dual Head	Dual Head	Dual Head	Dual Head
Screw Exterior Dia.	65	85	115	155	200	250
Ratio L/D	4	4.3	4.8	4.43	4.35	4.5
Condensation Ratio		1.3	1.3	1.34
Screw Rotate Speed r/min	20.27.35.47	28.40.56.80	33.46.60	27-81	22.4-67.2	19.7-59.1
Motor Power kw	7.5	11/15	22	18.3-55Commutator Motor	25-75Commutator Motor	33.3-100Commutator Motor
Throughput kg/n	50-80	70-210	100-420	700-1200	1500-2200	2000-3200
Steam Pressure Mpa	0.2-0.3	0.3-0.4	0.4-0.6	0.6	0.6-0.8	0.6-0.8
Cold Moving Water Pressure Mpa	0.2-0.3	0.2-0.3	0.2-0.3	0.2	0.2-0.3	0.2-0.3
Condensed Air Pressure Mpa					0.3-0.6	0.6
Overall Size: LxWxH(mm)	1630x604 x1050	2050x700 x1200	1630x604 x1050	3411x814 x1470	4564x1800 x1750	4950x1150 x1483
Product Weight kg(not include the head)	1200	2500	3000	5000	8000	11400

open mixing mill

Detail

Type XK-150 XK-250 XK-300 XK-360 X(S)K-400 X(S)K-450 X(S)K-560 Working diameter of rolls (mm) 150 250 300 360 400 450 560 Working length of rolls (mm) 320 620 750 900 1000 1200 1530 Working linear speed of front roll(m/min) 8 15.1 15.1 16.25 18.65 24.5 27.7 Max gap (mm) 10 10 10 10 15 15 15 Capacity per.batch(kg) 1-2 10-15 15-20 20-25 18-35 25-50 50-65 Driving motor power(kw) 7.5 18.5 22 30 37 55 95 Overall dimension (mm) L 1080 3400 3580 3940 4250 5200 6120 W 796 1350 1550 1780 1850 2380 2280 H 1415 1500 1695 1740 1870 1770 2000 Weight (kg) 1100 3500 5205 5670 7600 13000 22000 Notes Bearing Nylon bush grease LUB Copper sleeve oil LUB
