5000L Magnetic Coupling Stirring Hydrothermal Synthesis Kettle Jacketed Chemical Reactor
| US$46,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
FCHA-5000L
Type
Reaction Kettle
Material
Customized
Structure
Jacket and Coil Tube
Pressure
Customized
Agitator Model
Customized
Tower Reactor Type
Customized
Heating
Customized
Heat Transfer Structure
Combined
Automatic Grade
Automatic
Condition
New
Specification
5000L
Trademark
LUHAO
Origin
China
HS Code
84198990
Product Description
| MODEL | FCHA300-800L | FCHA800-2000L | FCHA2500-5000L | FCHA6000-10000L | FCHA12000-20000L |
| CAPACITY | 300-800L | 800-2000L | 2500-5000L | 6000-10000L | 12000-20000L |
| WORK PRESSURE MPa | -0.1-10.0 | -0.1-10.0 | -0.1-10.0 | 0.1-10.0 | -0.1-810.0 |
| WORK TEMPERATURE C° | -15-320 | -15-320 | -15-320 | -15-320 | -15-320 |
| rpm | 0-320 | 0-320 | 0-320 | 0-320 | 0-320 |
| Motor power KW | 1.5-5.0 | 7.5-11.0 | 11.0-22.0 | 22.0-30.0 | 37.0-45.0 |
| Main materials | 09MnNiDR/16MnDR (low temperature steel), 15CrMoR (high temperature steel), stainless steel S30408/S32168/S31603, S39042. Titanium material, duplex steel, shackle material, Hastelloy alloy, zirconium material, Monel, etc., and explosive composite plates made of these materials. | ||||
| Heating form | Jacketed thermal oil, jacketed steam, outer half pipe, inner coil pipe. | ||||
| Mixing form | Disc turbine type, three blade propeller type, asymmetric turbine type, disc inclined blade, parabolic type, four wide blade, propulsion type, propeller type, anchor type, etc. | ||||
| Shaft sealing form | Magnetic coupling drive with static sealing, zero leakage, long service life, simple installation, safe and environmentally friendly. | ||||
| Remarks | Other special requirements, touch screen intelligent control, program control, and connection to DCS systems shall be designed, manufactured, and configured according to user needs. | ||||
