Big Type CNC Vertical Lathe, C5225g*H*2 C5231g*H*20 C5240g*H*20
Basic Info.
Model NO.
C5225G*H*2 C5231G*H*20 C5240G*H*20
Type
Horizontal Lathe
Controlling Mode
CNC
Automatic Grade
Automatic
Precision
High Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Product Name
CNC Vertical Lathe Machine
Model
C5225*G*H*20
Max Turning Diamete
2500mm
Max Workpiece Height
1600/2000/2500mm
Workbench Diameter
2250mm
Max Workpiece Weight
20000kg
Main Motor Power
55
Weight
34/38/41t
Transport Package
Plywood Case
Trademark
Millart
Origin
China
Production Capacity
200units/Month
Product Description
Product description:Technical parameter :
Technical parameter :
| Item | Unit | C5225G*H*20 | C5231G*H*20 | C5240G*H*20 |
| Max turning diamete | mm | 2500 | 3150 | 4000 |
| Max workpiece height | mm | 1600/2000/2500 | 2000/2500/3150 | 2000/2500/3150 |
| Workbench diameter | mm | 2250 | 2830 | 3150 |
| Max workpiece weight | kg | 20000 | 20000 | 20000 |
| Max torque of workbench | KN.m | 50 | 50 | 50 |
| Workbench rpm level | Two stepless speed | Two stepless speed | Two stepless speed | |
| Workbench rpm range | r/min | I gear 0.63*21/II gear 2-63 | I gear 0.63*21/II gear 2-63 | I gear 0.63*21/II gear 2-63 |
| Tool post rapid feed speed | mm/min | 4000 | 4000 | 4000 |
| Tool post feed speed range | mm/min | 0.5~1000 | 0.5~1000 | 0.5~1000 |
| Ram crossface | mm | 250*200 | 250*200 | 250*200 |
| Main motor power | kw | 55 | 55 | 55 |
| Machine weight | T | 35/38/41 | 42/45/48 | 52/55/58 |
Company information:
FAQ
Q: Are you a trading company or a physical factory?
A: We are a specialized physical factory for more than 10 years. Our machines also gained CE certificate, ISO9001 and EAC certificate.
Q: What's your main products of your company?
A : We specialized in Vertical Machining Center, CNC Lathe, Milling Machines, Lathes, Drilling Machines, Saws, Shapers and so on.
Q: Can you provide customized machine?
A: Yes, we provide customized service for customers to meet different requirements.
Q: Can we visit your factory?
A: Sure, we warmly welcome you to visit our factory at any time. The more you know about us, the more you will trust us! So you can rest assured on our quality machines and our best service.
Q: What's the Payment Terms ?
A : T/T ,30% deposit when order ,70% balance payment before shipment ; Irrevocable LC at sight.
Q: What is your trade terms?
A: FOB, CIF ,DDP and CFR all acceptable.
