Highly Efficient Hydraulic Dump Electric Three-Wheeled Motorcycle Suitable for Powerful Cargo Transportation
| US$770.00 | 50 Pieces (MOQ) |
Basic Info.
Model NO.
CJ -DH06
Certification
RoHS, ISO 9001:2000, ISO 9001:2008, CE
Usage
Cargo
Body Type
Open
Wheel Distance
2100mm
Battery
Lead-Acid Battery
Driving Type
Adult
Curb Weight
420kg(Weight Including Battery)
Max. Speed(Full Load)
40km/H
Gradeability(Full Load)
20%
Battery Capacity
60V/58ah/Lead-Acid Maintenance-Free Battery
Motor
60V/1500W Permanent Magnet Synchronous Motor
Transport Package
CKD
Specification
2950*1100*1850mm
Trademark
CHANGJIANG
Origin
China
HS Code
8711600010
Production Capacity
50000
Packaging & Delivery
Package Size
305.00cm * 120.00cm * 195.00cm
Package Gross Weight
420.000kg
Product Description
Product Description LCD digital display instrument,front/rear 4.50-12 Steel wire tire,43mm diameter hydraulic shock absorber,Changan integrated afterburner teeth pack rear axle, 180mm brake pot,60V/1500W Permanent Magnet Synchronous Motor,Electric hydraulic dump, simple front windshield, electric wipers, mobile phone charger, spare tire, helmet, air pumpDetailed Photos
Product Parameters
| product name | CJ -DH06 |
| Items | Details |
| Vehicle size(mm) L*W*H: | 2950*1100*1850 |
| Cargo box size (L*W*H) mm: | 1640*1100*510 |
| Wheel base(mm): | 2100 |
| WHeeL Track (mm): | 960 |
| Ground clearance(mm): | 280 |
| Curb weight: | 420kg(Weight including battery) |
| Maximum load capacity: | 900kg |
| Max. Speed(full load): | 40km/h |
| Gradeability(full load): | 20% |
| Continued mileage: | 60-70km |
| Headlamp: | LED headlight |
| Motor Meter: | LCD digital display instrument |
| Frame: | 40*60 (mm) keel, 40*60 (mm) rear flat frame |
| Breaks: | Drum Break |
| Grears: | (High and low gear)+(Drive /Reverse) |
| Tyres model: | front/rear 4.50-12 Steel wire tire |
| Front Damper: | 43mm diameter hydraulic shock absorber |
| Rear Damper: | Cylinder spring damper |
| Rear axle: | Changan integrated afterburner teeth pack rear axle, 180mm brake pot |
| Leaf spring: | 6 pieces/60mm*8mm steel plate, double steel plate |
| battery capacity: | 60V/58Ah/lead-acid maintenance-free battery |
| Motor: | 60V/1500W Permanent Magnet Synchronous Motor |
| Motor Control Unit: | 24 tubes |
| Charging time: | About 6 -8Hours/ |
| Wiring Harness: | IP54 Waterproof Level IP54/ |
| Standard: | Electric hydraulic dump, simple front windshield, electric wipers, mobile phone charger, spare tire, helmet, air pump |
| Loading quantity: | 50 units CKD /40'HQ |
2. High-quality products: Our products undergo strict quality control and testing to ensure that they meet the highest quality standards.
3. The company adopts a combination of industry and trade, which greatly provides convenience for customers.
4. Competitive prices: We offer competitive prices and flexible payment methods to meet customers' budgets and needs.
5. Timely delivery: We are committed to delivering products on time.
