Pengxian High Security Fence Different Types Stainless Galvanized Square Steel Net Price of Welded Gabion Panel Lowes Concrete Wire Fencing Mesh Roll 20X20

Product Description

PENGXIAN High Security Fence Different Types Stainless Galvanized Square Steel Net Price Of Welded Gabion Panel Lowes Concrete Wire Fencing Mesh Roll 20X20PVC-COATED AND GALVANIZED WELDED WIRE MESH FENCE PANELS
Our factory provides a variety of welded wire mesh panels (also called welded wire fence panels), which are made of superior quality welded wire mesh, with flat even surface, and firm structure. Welded wire panels are used extensively in building, food, agriculture, and so on. It mainly serves as fencing mesh.
Material: low carbon iron wire, rib wire, deformed bar, stainless steel wire, etc. The biggest deformed bar we can deal with is 12 mm.
STAINLESS STEEL WELDED WIRE MESH PANELS
According to the difference of material, stainless steel welded wire mesh could be classified as the following types:
302 stainless steel: Low-grade stainless steel alloy, very economical cost, and produced as a standard stainless grade.
304 stainless steel: Most common stainless alloy used in wire weaving. Excellent corrosion properties and can withstand temperatures of 1100 Degrees F.
304L stainless steel: Similar properties as 304ss but lower carbon content to permit better welding.
310 stainless steel: A high-temperature nickel alloy that has excellent corrosion properties. Can withstand high operating temperatures up to 1800 degrees F for extended time periods.
316ss stainless steel: Similar properties to 304ss but is stabilized by the addition of Molybdenum for increased resistance to chemical corrosion.
316L stainless steel: Similar properties as 316ss but lower carbon content to permit better welding.
317L stainless steel: Increased corrosion resistance compared to 316ss. L grade allows better welding.
321 stainless steel: Similar to 347ss and can handle high operating temperatures. Has the addition of titanium.
330 stainless steel: This alloy can handle operating temperatures up to 1650 Degrees F. Common applications include heat-treating fixtures & baskets.
347 stainless steel: Has similar properties to 304ss but has the addition of Columbium for stability in high operation temperatures.
410 stainless steel: Has very good resistance to corrosion & oxidation.
430 stainless steel: Has magnetic properties similar to carbon steel but with much higher corrosion resistance. Commonly used in the food processing industry.The types of welded wire panels:
Welded stainless steel wire mesh panels.
Hot-dip zinc plating welded mesh panels.
Galvanized welded mesh panels.
Low carbon welded mesh panels.
PVC-coated welded wire mesh panels.
Steel Rebar Welded Wire Mesh Panel.
Sizes: Low carbon (black or galvanized) welded wire mesh with wire diameter from 0.8 mm to 1.5 mm, mesh opening 25.4 mm × 12.7 mm, width 800 mm - 1600 mm.
Property: Welded wire mesh panels can enjoy such properties as corrosion resistance, aging resistance, sunshine resistance, and weather resistance. Forms of corrosion resistance include electric galvanizing, hot-dipped galvanizing, PVC spraying, and PVC coating.
Benefits: Welded mesh panels can provide safety where security is needed. And welded wire fence panels are ideal in-fill for welded mine support mesh, machine guards, store partitions, dispatch areas, window guards, perimeter fencing, and similar barrier against unwanted intruders. Welded Mesh also is used where wire mesh and lacing are required to maintain the integrity of tunnels and other large underground excavations.Product ParametersGALVANISED WELDED MESH PANELS
4"×4" Galvanized Wire Panels
Common size to USA market:
4"×4" welded and galvanized panels
Panel size: 6' x 10', 48" x 72"
For plant growing trellises.
Welded Wire Panels
Common size to Canada market:
Welded wire panels, 8 ft x 8ft. x 3/16" diameter wire 2x4" openings.
Welded wire panels, 2.43m x 2.43m panels x 5mm wire diameter, openings 50.8mm x 101.6 mm.
Welded Mesh Panel
Common size to Belgium market:
Panel size: 2mx1m
Mesh: 52.9x53,3mm
Wire diameter: 1.72-1.75mm
Unit weight: 1.3kg
Welded Mesh Panels, Pitch of wires (mm): 200 x 200, Diameter of wires (mm): 10 x 10,
Sheet size: 4.8m x 2.1m

Specification
Opening		Wire Diameter
Inch	metric Unit(mm)
1"x1"	25mmx25mm	2.5mm,2.0mm,1.8mm,1.6mm
2"x2"	50mmx50mm	2.5mm,2.0mm,1.8mm,1.6mm
2"x3"	50mmx70mm	6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm
2"x4"	50mmx100mm	6.0mm,5.0mm,4.0mm,3.0mm,2.0mm
2"x6"	50mmx150mm	6.0mm,5.0mm,4.0mm,3.0mm
2"x8"	50mmx200mm	6.0mm,5.0mm,4.0mm,3.0mm
3"x3"	75mmx75mm	6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm,1.6mm
3"x4"	75mmx100mm	6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm
4"x4"	100mmx100mm	6.0mm,5.0mm,4.0mm,3.0mm
5"x5"	125mmx125mm	6.0mm,5.0mm,4.0mm,3.0mm
6"x6"	150mmx150mm	6.0mm,5.0mm,4.0mm,3.0mm
Technical Note:
1.Standard Panel Length:0.5m-5.8m;Width:0.5m-2.4m
2. Special size available at request

GALVANISED AND PVC-COATED WELDED WIRE MESH
Plastic Coated Welded Mesh
1.9/2.4 X 50 X 50 X 1500mm x 25m rolls
2.0/2.5 X100 X 50 X 1500mm x 25m rolls
Vinyl Coated Welded Wire
Common size to the United Arab Emirates:
Vinyl coated welded wire 1" x 1" mesh 14 gauge
Roll size: 100-foot rolls, 50-foot rolls
Steel wire mesh rectangular 100x100mm confirming to BS 4483 D49 Grade 460N/mm2
Black Vinyl Coated Welded Wire Mesh
Mesh size for USA market:
1/2 x 1/2
3/4 x 3/4
1-1/2" square opening
Green PVC Coated Welded Wire Mesh
Common size to Canada: 3/4" green coated welded wire mesh, 100mm x100mm x 6mm diameter

Specification
Opening		Wire diameter
Inch	mm	BWG	mm
1" x 1"	25mmx25mm	14# - 11#	2.0mm - 3mm
2" x 1"	50mmx25mm	14# - 8#	2.0mm - 4mm
2" x 2"	50mmx50mm	14# - 8#	2.0mm - 4mm
3" x 2"	75mmx50mm	14# - 6#	2.0mm - 5mm
3" x 3"	75mmx75mm	14# - 6#	2.0mm - 5mm
4" x 2"	100mmx50mm	14# - 4#	2.0mm - 6mm
4" x 4"	100mmx100mm	14# - 4#	2.0mm - 6mm
5" x 5"	125mmx125mm	14# - 4#	2.0mm - 6mm
6" x 6"	150mmx150mm	14# - 4#	2.0mm - 6mm
Material: Low carbon steel wire
Surface treatment: Electro Galvanized, Hot dipped galvanized, PVC coated, Powder coated
Note: Special sizes and specifications can be made according to customers' requirements.

Stainless steel welded wire mesh can last long for corrosion resistance compared to galvanized welded wire meshes. There is no need for surface treatment, it itself has the feature of corrosion resistance. Welded steel wire mesh is ideal for mining, filtration, transportation, and so on.
STAINLESS STEEL WELDED WIRE MESH SPECIFICATION:

Stainless Steel Welded Wire Mesh
Opening		Wire Diameter (BWG)
In inch	In metric units (mm)
1/4" × 1/4"	6.4 mm × 6.4 mm	22, 23, 24
3/8" × 3/8"	10.6 mm × 10.6 mm	19, 20, 21, 22
1/2" × 1/2"	12.7 mm × 12.7 mm	16, 17, 18, 19, 20, 21, 22, 23
5/8" × 5/8"	16 mm × 16 mm	18, 19, 20, 21,
3/4" × 3/4"	19.1 mm × 19.1 mm	16, 17, 18, 19, 20, 21
1" × 1/2"	25.4 mm × 12.7 mm	16, 17, 18, 19, 20, 21
1-1/2" × 1-1/2"	38 mm × 38 mm	14, 15, 16, 17, 18, 19
1" × 2"	25.4 mm × 50.8 mm	14, 15, 16
2" × 2"	50.8 mm × 50.8 mm	12, 13, 14, 15, 16

Stainless steel welded wire mesh applications: Construction, buildings, agriculture, industry, and so on.
The package is in roll and in panels. Detailed Photos
