UL, CE Approved Gpg AC Induction/Reversible Micro Electric Motor 15W Waterproof Terminal

Product Description

UL, CE approved GPG AC Induction/Reversible Micro Electric Motor 15W Waterproof terminal
The main products are induction motor, reversible motor, DC brush gear motor, DC brushless gear motor, CH/CV big gear motors, Planetary gear motor ,Worm gear motor etc, which used widely in various fields of manufacturing pipelining, transportation, food, medicine, printing, fabric, packing, office, apparatus, entertainment etc, and is the preferred and matched product for automatic machine.
1)End cover and housing of motor is made of die-casting Aluminum,which is high precision,high strength and light weight. 2)The stator consists of silicon steel sheet stator core,copper coil,and insulating material,etc.
3)The rotor consists of laminated silicon steel sheet and aluminum cast conductor. 4)The rotor shaft is made of high-performance medium carbon alloy steel and processed by special technics.There are round shaft and gear shaft. 5)The bearing and oil seal is selected from well-known brand to ensure good running performance and sealing effect. 6)The wire is made from high temperature resistant and flame retardant material.
Please leave message or send inquiry.I will be back to you asap.
Motor Model

Specification of motor 15W 80mm Fixed speed AC gear motor
TYPE	Gear tooth Output Shaft	Power (W)	Frequency (Hz)	Voltage (V)	Current (A)	Start Torque (g.cm)	Rated		Start		Gearbox type
							Torque (g.cm)	Speed (rpm)	Capacity (μF)	Resistance Voltage (V)	Bearing gearbox	Middle Gearbox
Reversible Motor	4RK15GN-C	15	50	220	0.16	1800	1200	1200	1.5	500	4GN-K	4GN10X
		15	60	220	0.15	1500	955	1500	1.2	500	4GN-K	4GN10X

4RK15GN-C/4GN3~20K
4RK15GN-C /4GN25~180K
Gear Head Model

Gearbox torque table(Kg.cm)															(kg.cm×9.8÷100)=N.m
Output speed :RPM			500	300	200	150	120	100	75	60	50	30	20	15	10	7.5	6	5	3
Speed ratio		50Hz	3	3	7.5	10	12.5	15	20	25	30	50	75	100	150	200	250	300	500
		60Hz	3.6	6	9		15	18		30	36	60	90	120	180		300	360	600
Allowed torque	10W	kg.cm	1.7	2.7	4.2	5.5	6.8	8.3	11	13.5	16	26	40	50	50	50	50	50	50
	15W	kg.cm	2.4	4	6	8	10	12	16	19	23	39	50	50	50	50	50	50	50
	20W	kg.cm	3.2	5.3	8	10.5	13.3	16	21.3	25.3	30.5	50	50	50	50	50	50	50	50
	25W	kg.cm	4.0	6.7	10	13.3	16	20	26.7	32	39	50	50	50	50	50	50	50	50
	30W	kg.cm	4.8	8	12	16	20	24	32	38	46	50	50	50	50	50	50	50	50
Note: Speed figures are based on synchronous speed, The actual output speed, under rated torque conditions, is about 10-20% less than synchronous speed, a grey background indicates output shaft of geared motor rotates in the same direction as output shaft of motor. A white background indicates rotates rotation in the opposite direction.

Above drawing is for standard screw hole.If need through hole, terminal box, or electronic magnet brake, please let me know.
Connection Diagram:
