High Speed Ball Screw Plastic Mechanical Screw Special CNC Milling Machine

Product Description

LXK350C×5000 CNC screw milling machine
one. Machine tool profile
LXK350C type (external type) CNC screw milling machine is a series of screw processing machines developed by our company leading varieties, products are designed for processing such as lead, variable lead, gradual lead, such as groove depth, such as special screw machine.
LXK350C CNC screw milling machine has the following characteristics:
1, the whole bed design, three guide rail layout, guide rail surface high-frequency quenching, good rigidity, high precision.
2, the milling head adopts high power frequency conversion motor, which can make the milling cutter realize stepless variable speed and wide speed range. The milling head can be manually adjusted according to the requirements of the workpiece. The milling head can go up and down.
3, X axis and Z axis reciprocating motion using ball screw to achieve high repeatable positioning accuracy.
4, C axis drive for worm gear and worm structure, smooth transmission, accurate indexing.
5, the saddle is dovetail guide rail, high position accuracy, good fast speed.
6, the spindle bearing is lubricated by oil, low temperature rise, high durability, and no daily lubrication maintenance.
7, the machine tail seat is mechanical, flexible and reliable.
8, the machine is equipped with a wide range of control system.
9, the machine is equipped with chip discharging machine, the iron filings generated in the milling process directly into the chip discharging machine, to ensure the clean working environment.
10. The electrical components in the machine tool electrical control cabinet are delixi brand.
two .Main technical parameters of machine tool

Bed width	mm	800
The length of the lathe bed	mm	6700
Bed guide rail		Mountain track + horizontal track
Maximum workpiece length	mm	5000
Maximum machining length	mm	4700
Maximum milling diameter	mm	Φ 350
Center height of machine tool	mm	500
Chuck specifications		K11-500
Milling head motor power	Kw	11 (frequency)
Mill head transmission ratio		1:3.3
Milling cutter speed rating	r/ m in	400
Spindle mounting taper of milling head		7:24( Φ 69.85)
Milling head down adjustment range	mm	-5 ~ +10
Milling head adjustable Angle	The degree of	±30
C-axis servo motor torque	N. m	22
C shaft speed	r/min	0-5
C axis drive form		Worm gear and worm
C axis transmission ratio		1:300
C axis positioning accuracy	Angle of seconds	10
X axis servo motor torque	N. m	15
X axis drive form		Ball screw + synchronous wheel
X axis guide rail pair type		55 ° dovetail
X axis ball screw specifications		4005
X axis positioning accuracy	mm	0.02

Frequently asked Questions:
Q1, how do I send my query?
You can contact us via email, phone, instant messaging (WhatsApp, wechat, Skype).
Q2, if you do not know which model is suitable for your company, please tell us your requirements for the equipment, or you can send us product drawings and our engineers can help you choose the model that is best for you.
Q3, The project will be completed within 20 days after receiving the deposit. Please communicate with sales staff for specific period of time.
Q4, payment terms
30% through T/T as the down payment, the remaining 70% through T/T before delivery. If there are other terms of payment, we can discuss them. Inquiries are welcome.
Q5, can your engineer come to help us install and debug the machine?
Yes, our engineers can go to your location. Round-trip air tickets and accommodation are at your own expense.
Q6, if I don't know how to do it. Can your engineers help me program the machine well?
Of course. You can provide your detailed sample drawings. Engineers can program machines very well. Or on some machines, we'll put in a usb flash drive with the operation video to help you.
Q7, is there only one model of this device?
The standard processing diameter range of this equipment is 350mm, if there are other processing range can be negotiated with sales staff. Length range, we can do from 1000mm to 8000mm, and all are integral casting bed.
8. What control system does the equipment use?
Our standard configuration is Guangzhou CNC system, fanuc and Siemens can also be used, but the price is slightly different, please contact sales for details.

Q9. What control system does the equipment use?
Our standard configuration is Guangzhou CNC system, Fanuc and Siemens can also, but the price is slightly different, please contact sales for details.
