PFEA112-65 3BSE050091R65

Product Details

Product Description

Product Description
Brand:ABB
Type:PFEA112-65 3BSE050091R65
Origin: the Swiss
Warranty: 365 days
Colour: new/used
Shipping method: Courier delivery
Spare parts spare parts, the main DCS control system of PLC system and the robot system spare parts,
Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts
ABB recommends the use of connectors with built-in termination since the fieldbus will always be terminated even if fully disconnected from the unit. Functional Block Diagram Figure 69. Block Diagram – CI851 CI851 has been replaced by the CI854 communication interface. CI851 is only described for legacy reasons
F(ault) /Red Unit error detected. Controlled by Control Software. Set and cleared by the Hardware during controller Reset. R(un) /Green Operating. Controlled by the Control Software. Cleared by the Hardware during controller Reset. Rx/Tx /Yellow Transmission to or from the unit. RTS /Yellow Request to transmit from the unit. Table 77. CI851 PROFIBUS DP Interface Specifications Item Value Type DP Master Class I Protocol PROFIBUS DP Communication speed 9.6, 19.2, 93.75, 187.5, 500, 1500, 3000, 6000 or 12000 kbit/s Galvanic isolation Yes Status indicators Run normally green, Fault exceptionally red, the two traffic indicators RTS and Rx/Tx are yellow flashing controlled by the traffic pace. Connector DB9, female Current consumption (from CEX-Bus 24 V DC) 150 mA typical (200 mA max.) Power dissipation 3.6 W typical
Key Features • One FOUNDATION Fieldbus port provides a communication speed of 31.25 kbit/s (FF H1) • Transformer isolated • No power consumed from the FF H1 bus • No power is supplied to the FF H1 bus • Simple DIN-rail mounting • Pre-set, two letter Alpha code lock, see Table 4 on page 75, installed in unit base to prevent incorrect mounting of non-compatible components. Description The CI852, connects the FOUNDATION Fieldbus H1 (FF H1) to the AC 800M. The FF H1 has a communication speed of 31.25 kbit/s and is intended for remote connection of field instruments. The CI852 is connected to the bus via a transformer, and as such neither supplies nor consumes bus electrical power. The number of field instruments that can be connected via the CI852 depends on the physical limitations of the FF H1 network, together with any software limitations (refer to the software documentation). The FF H1 bus allows reuse of existing cabling for 4-20 mA analog signals. This means the cables often become the dominant dimensioning factor. An FF configuration tool can be connected directly to the FF H1 bus. CI852 has been replaced by the CI860 communication interface (together with the LD800HSE linking device). CI852 is only described for legacy reasons.
