Best Price Large Capacity New Japan Concrete Mixer Specifications for Sale

Product Description

1.Why choose us?TOBEMAC----CHINA Leading Construction Machinery Manufacturer We are manufacturer of Concrete Mixers Since 1991. We are certified by SGS;BV;SONCAP;PVOC;CE; ISO 9001:2015 We have a Professional Construction Machinery workshop which covers an area of 10000 sqm and its daily output for CONCRETE MIXER is 50 sets , so we can assure you the punctual delivery. Our main products include all kinds of Diesel Concrete Mixer,Electric Concrete Mixer,Concrete Mixer Truck, Hoisting Machinery, Road Machinery,Compactor Machinery,Block Machinery , and etc. Our company is near the NINGBO port , you are very welcome to come to our company. 2.Products Specification:

Main Technical Parameter
Model	JS500	JS750	JS1000
Discharging Capacity	500L	750 L	1000L
Loading Capacity	800L	1200L	1600L
Productivity	≥25m3/h	≥35m3/h	≥50m3/h
Discharge Height	1.5 m or 3.8m	3.8m	3.8m
Max. Size of Aggregate	80 mm	80 mm	80 mm
Number of Mixing Blade	2x7	2x7	2x8
Rotating Speed of Mixing Blade	31r/min	31 r/min	25 r/min
Mixing Motor Power	18.5 KW	30KW	37 KW
Hoist Motor Power	5.5 KW	7.5KW	11 KW
Water Pump Power	1.1 KW	0.75KW	3 KW
Total Weight	4500 kg	6500 kg	8500 kg
Overall Size (L×W×H)	4450×3100×5200 mm	5100×3600×6200	8700×3400×9500
Packing Size (L×W×H)mm	3000×2200×2500 mm	3700×2250×2500	4600×2250×2550
Container Loading Plan	1Set/20GP, 3 Sets/40HQ	1 Set/20GP, 3 Sets/40HQ	2 Sets/ 40HQ

3.Product Application
(1).Description of twin-shaft concrete mixer:
JS500-1500 self loading concrete mixer developed by our company is widely used by our global users.
This self loading concrete mixer can be used as a separated mixing machine or used as the
supporting machine of the concrete mixer.
(2).Features of twin-shaft concrete Mixer:
1. As a miniature double-horizontal-shaft forced type portable concrete mixer , this self loading concrete mixer features short mixing time, good homogeneity and reliable operation.
2. Shaft tip is sealed by floating-ring, which is reliable and easy to maintain and replace.
(3).Application of twin shaft concrete mixer:
(1)This series of Mixers are designed according to GB/T9142-2000 standards. They have characteristics as reasonable structure, good mixing quality, short mixing time, low energy consumption and little noise etc.
(2)This series of mixers have unloading the form of a high degree of 1.5 m ,2.7 m ,3.8 m with the users concrete means of transport, such as :dump motor vehicles, Dump-dump car, concrete mixer truck, etc. The customers can make a unloading degree by their own requirements.
(3) This series of equipment has the advantages of single-machine independent operation. It can be used as a simple concrete mixing plant with PLD series batching machine. It can stir hard concrete, plastic concrete, fluidity concrete, lightweight aggregate concrete and various mortars, which is an efficient mixer.
(4) The series of product design structure is reasonable, easy to use and maintenance.The user can be equipped with a dump truck, self-loading truck, mixer, and it can be modified according to the special requirements of the user to meet the customer's needs.
JS serial double horizontal shaft compulsion type concrete mixer is a multi-function mixer,can be applied to mix dry-hard concrete,plastic concrete,light aggregate concrete and all kinds of mortar.
This mixer has characteristics of simple structure,high mixing quality,high efficiency,energy-saving,low noise,simple operation,and can be used together with dump car,truck and concrete mixing truck,its the ideal machine of construction sites,large and medium-sized concrete factories.
This self loading concrete mixer can be used to mix stiff-consistency concrete, semi-stiff-consistency concrete, light weight aggregate concrete and so on.
4.Production Flow
5.Our service
1.Installation, debugging, operators trainning;
2.Maintanence:
A. when trainning your operators, our engineers will give them advice on how to operate the machines correctly;
B. we will send you the operation manual which can help you operate the machins properly, it can also help you to solve the common problems;
C. Call us at any time if you have problems about our concrete mixers;
D. If needed, we will send engineers to your site to solve your problems.
3.Providing some documents needed for your customs clearance, like commercial invoice, packing list, certificate of origin etc;
4.Spare parts supply;
