10~24m Electric Hydarulic Aerial Towable Boom Lift

Product Description

Towable Boom Lift

YILU LIFT ® Features & Advantages
Use Germany ALKO brand brakes with high quality
Use Switzerland Bucher brand DC pump station
Use Japan Honda brand Gasoline pump station
Use China Famous YSD brand diesel pump station
Use waterproof and dust proof electrical box. Suitable for outdoors working.
Waterproof control panel can be used when raining.
Self Levelling sole for efficient and safety operation
Water proof diesel engine, motor and battery cover
Humanized access hole for daily convenient maintenance
Manual Diesel engine accelerator much more flexible to operate.
Two way cylinders with balance valve and emergency decline switch. Even hydraulic hose rupture, platform will none drop down to guarantee completely safe.
Equipped with basket levelling switch, make adjust basket much more easier.
Equipped with Torsion Shaft with great shock absorption function, which make it better at walking on road.
Hydraulic oil filtration alarm system, remind you replace hydraulic oil when there is impurity in the oil.
Basket and Arm lock system avoid equipment body waggling during transportation.
Humanized Flood lights on platform for working Equipped with brake lights connected with tractor.
Equipped with caution lights on each legs.
Anti-pinch hand basket.
Equipped with safety harness to protect operator.
Stable Rotary motor,360°rotation.
Wide Horizontal reach from 5m to 10.5m
Max 120Km/h Towing Speed
Multi power for choice, such as AC,DC, AC&DC, Diesel, Gas and so on.
Offer FREE quick wear parts for quick replacement

Model			TBL-10A	TBL-12A	TBL-14A	TBL-16A	TBL-18A	TBL-20A
					+Telescopic	+Telescopic	+Telescopic	+Telescopic
Lifting height			10M	12M	14M	16M	18M	20M
Working height			12M	14M	16M	18M	20M	22M
Load capacity			200KG
Platform size			0.9*0.7M
Working radius			5.5M	6.5M	8.5M	10.5M	11M	11M
Net Weight			1855KG	2050KG	2500KG	2800KG	2800KG	2800KG
Overall Size( L*W*H)			5.2*1.7*2.1M	6.2*1.7*2.1M	5.6*1.7*2.1M	5.7*1.7*2.2M	6.5*1.8*2.3M	5.8*1.9*2.3M
Supporting Legs Stride Distance(Horizontal)			3.0 M	3.6 M	3.6 M	3.9 M	3.9 M	3.9 M
Supporting Legs Stride Distance (Vertical)			4.7 M	4.7 M	4.7 M	4.9 M	4.9 M	4.9 M
Wind Resistance Level			Not More Than 5
20'/40' Container Loading Quantity			20'/1set	20'/1set	20'/1set	20'/1set	20'/1set	20'/1set
			40'/3sets	40'/2sets	40'/2sets	40'/2sets	40'/2sets	40'/2sets

1. Imported key components, suck as Switzerland Bucher DC Pump, Japan Honda Gas Pump, Germany ALKO Brakes..
2. Waterproof and dust-proof electrical cabinet.
3. Self-Levelling anchor pad.
4. Maintenance hole
5. Hydraulic oil filtration system.
6. High performance rotary motor allows for 360° rotation.
7. Horizontal reach as long as 5m to 10.5m.
8. Max 40km working speed.
9. AC, DC, AC&DC, Diesel, Gas power sources available.
10.Free quick wear parts for replacement.

Safety Precautions
1. Anti-burst valve prevents accident in case of hydraulic hose rupture.
2. Spillover valve releases pressure when necessary.
3. Emergency decline valve allows for descent amid power failure.
4. Anti-dropping device prevents fall while in operation.




FAQ

1: How to place an order?

Answer: Please tell us your detailed requirements (including your product materials, product dimensions and product weight), and we will send you detailed parameters and quotations as soon as possible.

2: What is your price?

Answer: It depends on your requirements of the equipment and shipment terms (FOB, CIF, DDP)

3: How should I pay?

Answer: We accept wire transfer; letter of credit;trade guarantee.

4: What is the delivery time?

Answer: For the standard product, the delivery time is 7 days.For customized orders with no stock, we need to determine the delivery time according to the situation, if you need urgent items, please contact us.

5: About the warranty

Answer: 1-year warranty. Lifelong technical support via email or video.

6: About the guarantee

Answer: MIC will protect the order. We have trade assurance.

7: Mode of transportation

Answer: You can choose sea, air, rail transportation.
