4 Channels Output Durable Using RJ45 RGBW Output Constant Voltage DMX512 Decoder

Product Description

Products Description PX0408 adopt the advanced micro-computer control technology and converted the DMX512,RDM/2009 digital signal widely used in international to the PWM control signal. 1~4 channels output for option and each channel able to achieve 256 gradations of controlling, and also it can be used as the connector of PC digital light controller and analog light modulator. It is mainly used for the controlling of buildings & lights applied LED.

Product Name	4 Channels Output Durable Using RJ45 RGBW Output Constant Voltage DMX512 Decoder
Material	Metal
Colour	Black
Input Voltage VAC	12~24VDC
Output Current & channel mA	6A*4 channel
Output Voltage VDC	12~24VDC
Output Power W	288W(12V)/576 W(24V)
Dimming	DMX512

Product Feature · Meets DMX512/1990,RDM /2009 protocol · Supported RDM parameters: DISC_UNIQUE_BRANCH DISC_MUTE DISC_UN_MUTE DEVICE_INFO SOFTWARE_VERSION_LABEL DMX512/RDM_START_ADDRESS IDENTIFY_DEVICE MANUFACTURER_LABEL SUPPORTED_PARAMETERS · In DMX mode set the DMX address manually by switch; in RDM mode, the host computer address allocation · Constant voltage output, the maximum current of 6A /ch for RGBW decoder · 256 grade brightness adjustment · Short-circuit protection,overload protection,over-temperature protection ·Flicker-free FAQ A) How could I get a sample? Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order. B) Lead time? Existing items: Within 1 day after payment received. New items:About 4-6 weeks after payment received. C) Whether you could make our brand on your products? Yes. We can print your Logo on both the products and the packages if you can meet our MOQ. D) Whether you could make your products by our color? Yes, The color of products can be customized if you can meet our MOQ. E) How to guarantee the quality of your products? 1) Strict detection during production. 2) Strict sampling inspection on products before shipment and intact product packaging ensured.
