Industrial Water Softener with Water Softening and Pretreatment Features

Product Description

Product Description
What is the water softener? Allow us to introduce you to the essence of water purification technology.An ion exchange water softening device is ingeniously crafted to eliminate calcium (Ca²+) and magnesium (Mg²+ions from hard water through a meticulous chemical exchange process. It leverages resin beads infused with sodium (Na+) ions, effectively substituting hardness ions, thereby diminishing scale build-up and elevating water quality to new heights.Features and Core Advantages: Discover an array of features that set our product apart from the ordinary.Automated Operation: With state-of-the-art programmable control valves, our system automates ion exchange processes and resin regeneration cycles, vastly reducing the need for manual intervention and ensuring seamless operation.High-Capacity Resin: Expertly utilizing synthetic food-grade ion exchange resin (e.g., 001×7 type) with superior adsorption capacities, guaranteeing meticulous removal of hardness ions.Salt-Based Regeneration: Employing sodium chloride (NaCl) to rejuvenate the resin by efficiently expelling accumulated calcium and magnesium ions, thereby restoring the resin's unparalleled softening capabilities.Compact Design: Meticulously engineered for optimal space utilization, rendering it ideal for a wide range of settings, from residential to commercial, and even industrial installations
.Corrosion-Resistant Materials: Features such as fiberglass-reinforced tanks are incorporated to ensure remarkable durability and longevity of performanceScale Prevention,Eco-Friendly and Cost-Effective: Delivers water with a hardness level ≤0.03 mmol/L, conforming to international standards for drinking water safety, while being gentle on the environment and your budget.Product Parameters
Feed Water Pressure: 0.2Mpa-0.4Mpa - The ideal pressure range to ensure optimal performance
Working Temperature: 2-40ºC - Operates efficiently in a wide temperature span
Power supply: 380V/220V/50Hz - Compatible with standard voltage requirements
Feed Water Hardness: ≤6.4mmol/l - Suitable for varied water quality conditions
Output Water Hardness: ≤0.03mmol/l - Ensures superior water softening results
Operation Mode: Automatic operating - Simplified user experience with minimal intervention needed
Regeneration: Downstream regeneration or Countercurrent regeneration. - Flexible options for efficient resin use
Resin: Cation Exchange Resin. - High-quality resin for effective ion exchange

Model No.	Filter Tank size(mm)	Salt Box Volume(L)	Media Volume(L)	Automatic Softner contral valve
XTHB-1T/H	1054(250*1350)	60	50	F65P
XTHB-2T/H	1265(300*1340)	100	75	F63P
XTHB-3T/H	1465(350*1650)	100	125	F63P
XTHB-4T/H	1665(400*1650)	200	150	F63P
XTHB-5T/H	2069(500*1750)	200	250	F74A
XTHB-6T/H	2465(600*1850)	300	350	F74A
XTHB-10T/H	3065(750*1850)	500	525	F74B
XTHB-15T/H	3665(900*1900)	800	750	N77A
XTHB-20T/H	4079(1000*2200)	1000	950	F95A
.......

Detailed Photos
Successful Project
Packaging & ShippingAt Hunan Xinhaoyuan Water Treatment Equipment Co., Ltd., we are dedicated to excellence in Packaging & Shipping, offering a range of robust and reliable packaging solutions specifically tailored for your unique needs. Our premium selections include sturdy wooden cases and resilient wood frame packing, both designed meticulously to provide unparalleled protection. With our customized packaging, your precious goods are shielded against any potential damage during their extended transportation journey, ensuring they arrive at their destination in impeccable condition, just as they left our hands. Trust in our commitment to preserving the integrity and quality of your products with every shipment.
Company ProfileHunan Xinhaoyuan Water Treatment Equipment Co., Ltd. is a collection of water treatment equipment technology innovative research and design, water treatment equipment manufacturing,installation,commissioning ,sales and after-sales service integrated high-tech enterprise.The factory is established in 2009,located in Zhuzhou City,Hunan,China. It areas more than 3000 square meters and has nearly 40-60 talented&trained staffs to work out abundant professional and rest-assured turnkey projects with more than 15 years experience.
We specialize in customized diverse RO drinking water system and plant for residential,commercial and industrial,as well as the customized industrial pure water and ultra-pure water equipment for foodbeverage,dairy product,lab and pharmaceutical etc . Also we have professional experience in wastewater ,seawater,brackish water treatment,such as smart-integrated residential wastewater treatment system, industrial wastewater treatment,seawater, brackish water desalination treatment.
A wide range of products include Reverse Osmosis(RO) System,Ultrafiltration (UF) System, Nanofiltration(NF) system,EDI(Electrodeionization ) Ultra pure water,Mix Bed,Water Softeners,Dosing System,Chemical Agent,Ozone Generator disinfecting system,Ultraviolet sterilizer etc.All the products are recognized high by client from home and abroad.Welcome to visit our factory!FAQAre you a factory or trading company?We are a professional water treatment equipment manufacturer for more than 15 years experience in water and wastewater treatment system design, equipment manufacturing, on-siteinstallation, commissioning, after-saleservice.The factory areas 3000 square meters, located in Hunan,China.Welcome to visit us for better understanding.
2.What's your main products?We supply a full range of commercial and industrial water treatment equipment and other related spare parts and accessories, including Ultrapure Water Equipment, Industrial Reverse Osmosis Equipment, Deionised Water Equipment, Softened Water Equipment, Water Reuse Equipment, EDI Ultrapure Water Equipment, Iron and Manganese Filters, Ultrafiltration Water Purification Equipment, etc. And other accessories, such as RO/NF/UF/MF Membranes, FRP/Stanless Steel Housing, Water Tanks, Valves, UV Sterilisers, Ozone Generators, Chemical Dosing Equipment, etc.
3.How can I get the equipment installed ?
The equipment is fully assembled and installed in our workshop,and tested before shipping. Also,we can provide installation manual ,installation video ,remote on line installation guiding or on-site installation if needed.
4.Any warranty on your equipment?Yes, we offer a 12-18 month warranty on most core elements with regular use and maintenance.
