Cfjg-Sk-150 Automatic Spiral Cardboard Core Winding Paper Tube Making Forming Machines Small Business Idea
| US$20,000.00 | 1 sets (MOQ) |
Basic Info.
Model NO.
CFJG-SK-150
Paper Core Usage
Industry
Gumming Type
Double Side
Certification
CE
Condition
New
Processing Type
Winding Machine
Dimension(L*W*H)
4600*1950*1900mm
Showroom Location
Canada, Turkey, Italy, Peru, Saudi Arabia
Weight
4500 Kg
Warranty of Core Components
1.5 Years
Video Outgoing-Inspection
Provided
Applicable Industries
Manufacturing Plant
Marketing Type
Ordinary Product
Core Components
PLC, Motor
Product Type
Paper Core Machine
Voltage
380V / 3phase / 50Hz (Customizable)
Power
15kw
Brands of Components
Can Be Cutustomized
Machinery Test Report
Provided
Transport Package
Seaworthy Packing (Wooden Case / Pallet)
Trademark
Chuangfeng
Origin
Zhejiang, China
Production Capacity
30 Set/Sets Per Month, 1-25m/Min.
Product Description
CFJG-SK-150 Automatic Spiral Cardboard Core Winding Paper Tube Making Forming Machines small business idea Product Description CFJG-150 Large size tube & core making machine is suitable for packing cores; textile cores and other industrial paper tubes & cores.-- PLC controlled Automatic Paper Core Making Machine adopts Computerized Control System. All the working parameters can be setup on the controlling panel (touch screen type) .
-- Single circular blade inline cutting system with cutting range 500-5000mm.
-- All the brands of components like Motor; Inverter; PLC; Touch Screen can be customized as per your requirement.
Technical Parameters
| Technical Parameter | Control System | ||
| Paper Layer | 25 Layers | Main Motor | 15kw Wannan |
| Inner Diameter | 50-250mm | Inverter | Schneider |
| Wall Thickness | 1-15mm | PLC | Xinjie |
| Winding Speed | 1-25 meters/min | Operating Panel | Panel Master |
| Speed Regulation | by Inverter | Electric Components | Schneider |
| Winding Heads | Four heads double belts | Pneumatic Components | Jingwei |
| Shaft Fixing | by Flange | Bearing | Haerbin |
| Cutting Blade | High Speed Steel Blade | Power Supply | 380V 3 Phase 50Hz |
| Cutting Length | 1000-5000mm | Main Configurations | |
| Gluing Way | Double Sides | Paper Reel Stand | 24 Layers Integral Type |
| Length Fixing | by Infrared | Gluing System | 24 Layers Spraying Type |
| Working Air Pressure | 0.6Mpa | Inner Paper Stand | 1 Set |
| Operator | 1-2 persons | Tube Unloading Shelf | 1 Set |
| Measurement & Weight | Mandrel Shaft (mold) | 2 Pieces | |
| Measurement | 4600*1950*1900mm | Belt | 4 Pieces |
| Working Space | 10000*5000mm | Blades | 5 Pieces |
| Total Weight | 4500kgs | Useful Tool | 1 Set |
Four-heads Double-belts Spiral Winding
Online cutting system - controlled by AC motor; cutting length 1000-5000mm
Equipped with 24 layers paper reel stand *1set
Equipped with 24 layers spraying glue unit *1set
Finished tube unloading shelf * 1 set
Finished Products
