Mobile Tree Shredder Diesel Pallet Crusher Industrial Log Grinder Wood Drum Chipper
| US$8,000.00-9,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
216
Automatic Grade
Semi-Automatic
Warranty
1 Year
Name
Chipper Shredder Crusher Grinder
Motor
55 Kw
Capacity
3-5 Tons Per Hour
in Feeding Conveyor
6 Meters
out Feeding Conveyor
10 Meters
Transport Package
Customized
Specification
Customized
Trademark
Customized
Origin
China
HS Code
8465960000
Production Capacity
200 Sets Per Year
Packaging & Delivery
Package Size
350.00cm * 120.00cm * 200.00cm
Package Gross Weight
3500.000kg
Product Description
Product Description1. Designed for round logs, square blocks, wood staff.
2. Including Main Body,Knife Rotor,In and out feeding System,Hydraulic System,Electric Control System
3. Widely used in the factories of flake board, fiberboard, paper making.
4. Chipping big wood logs, wood planks for biomass pellet production.
Product Parameters
Wood Chipper Branch Shredder Crusher Grinder
Popular and highly trusted in Australia,Chile,Fiji,Guatemala,Indonesia,Italy,Malaysia,
Mauritius,Philippine,Russia,South Africa,Sigapore,Thailand,UAE,UK,USA,Vietnam,Zambia,
| Model | WS216 | WS218 |
| Blade Roll Diameter | 650MM | 800MM |
| Roller Speed | 650RPM | 650RPM |
| Knife Quantity | 2PCS | 2PCS |
| Feeding Inlet | 240*540MM | 400*700MM |
| Production Capacity | 3-5 Tons/Hour | 6-8 Tons/Hour |
| Motor Power | 55KW | 90KW |
| Feeding Motor | 3KW*1 , 4KW*1 | 4KW*1,5.5KW*1 |
| Outlet Motor Power | 3KW-6 *2 | 3KW-6*2 |
| Oil Pump Motor Power | 1.5KW | 1.5KW |
| Feeding Conveyor | 6 Meters | 6 Meters |
| Outlet Conveyor | 10 Meters | 10 Meters |
Detailed Photos
Raw Materials
Related Machines
Wood Disk Chipper
| Model | WS300 | WS450 | WS500 |
| Feeding Inlet MM | 300*300 | 450*450 | 500*500 |
| Blade Roller Diameter MM | 1200 | 1600 | 1800 |
| Blade Quantity | 6 | 6 | 6 |
| Motor Power KW | 90 | 185 | 220 |
| In Feed Conveyor Meters | 8 | 8 | 8 |
| Out Feed Conveyor Meters | 10 | 10 | 10 |
| Wood Chips Size MM | 20-35 | 20-35 | 20-35 |
| Capacity Tons/Hour | 15 | 20 | 25 |
| Weight KGS | 3300 | 6500 | 9600 |
Wood Branch Crusher
| 80HP 60KW Diesel Engine Brand | HUA DONG / WEI CHAI |
| Double Side Blade Quantity | 4 Moving +1 Fixed |
| Cutting Branch Size | 5-200MM |
| Blade Shaft Diameter | 540MM |
| Forced Feeding Control | Intelligent |
| Capacity | 3-5T/H |
| Feeding Inlet Length | 1845MM |
| Feeding Inlet | 470*440MM/1320*690MM |
| Hydraulic Oil Tank | 600*260*430MM |
| Electric Start | 24V Battery |
| Tyre | 600-1617 |
| Walking | PTO |
| Power Input | Reverse Charging Mode Of Power Operation |
| Overall Size | 4600*1800*2900MM |
| Weight(kg) | 3000 |
Horizontal Wood Splitter
| Model | WS1200 | WS1500 |
| Motor Power | 15 | 18.5 |
| Stroke | 1200 | 1500 |
| Forward Speed | 80MM/S | 80MM/S |
| Backward Speed | 120MM/S | 120MM/S |
| Max Thrust 16MPA | 30T | 50T |
| Weight | 2200KG | 3000KG |
Double Rotor Log Debarker
| Model | WS6000 | WS9000 |
| Production Capacity | 5-10T/H | 10-15T/H |
| Motor Power | 11KW*2 | 15KW*2 |
| Log Diameter | 50-250MM | 50-250MM |
| Log Length | 6000MM | 9000MM |
Hammer Mill
| Model | WS700 | WS1100 | WS1500 |
| Feeding Inlet | 1000*600mm | 1000*700mm | 1000*800mm |
| Blade Shaft Diameter | 700mm | 1100mm | 1500mm |
| Blade Quantity | 84 | 84 | 84 |
| Blade Roll Speed | 2800R/M | 1450R/M | 1450R/M |
| Motor Power | 132KW | 160KW | 220KW |
| In Feeding conveyor | 10000mm | 10000mm | 10000mm |
| Out Feeding conveyor | 6000mm | 6000mm | 6000mm |
| Max Processing wood size | 20-50mm | 20-50mm | 20-50mm |
| Capacity | 3-4T/H | 5-6T/H | 8-10T/H |
| Double Auger Discharge,Integrated Electric Control Box,Soft Starter, | |||
Wood Grinder
Drum Chipper/Shredder/Crusher.Industrial chipping/shredding/crushing Machine
For Building Template,Wasted wood pallet,tree bark,slabs,offcuts,branches,straw....
| Feeding Inlet(mm) | 1400*600 |
| Blade Roll Diameter(mm) | 830MM |
| Blade Quantity | 4PCS=2 Group Fly Knife |
| Blade Roll Speed (R/Min) | 850 |
| Max Processing Wood Diameter | 450MM |
| Wood Chipper Size | 20-40MM |
| Production Capacity | 15-20 Tons/Hour |
| National Standard Copper Motor Power | 200 KW |
| Feeding Suspension Inverter Motor | 7.5KW*1 |
| 1400*6000MM 16Mn Chain Plate Feeding Inverter Motor | 11KW*1 |
| Electromagnetic valve integrated Oil Pump Motor | 3KW |
| Outlet 4 Layer Nylon Conveyor | 3 KW Gear Motor |
| 10*1*3.8-4.5Meters Outlet 4 Layer Nylon Conveyor | 7.5 KW Gear Motor |
Wood Stump Shredder
| Blade Quantity | 4 Fly Knife Or 26 Hammer |
| Feeding Inlet Diameter | 3600MM |
| Blade Shaft Size | 1600*850MM |
| Rotor Diameter | 800MM |
| Production Capacity | 25-30 TONS/Hour |
| Motor Power | 185KW |
| Outlet Conveyor | 12 *1.2Meters |
Packaging & Shipping
Company Profile
Specialize in research & development, production, sales of sawmills and the relevant fittings SINCE 1988
We have serves 11,000 enterprises and our products have been exported to over 60 countries in the world.
Our machine including:
Wood Splitter,
Wood Debarker,
Wood Chipper (Drum/Disk)
Branch Shredder,
Root Crusher,
Pallet Grinder
Hammer Mill,
Rotary Dryer,
Wood Pellet Machine
Wood Shaving Machine,
Hydraulic Baler
Wood Wool Machine,
Rope Machine
Sawmill & Kilns & Pallet & Biomass & Forestry & Recycling
Sincerely welcome worldwide distributors to join us!
