Factory Price Calcium Silicate Panel Raised Floor Sanding Machine

Product Description

Fiber Cement Calcium Sulfate Panel Raised Floor Grinding Line Sanding Machine
The raised floor panels with calcium sulphate core are considered the top of the range and is used in cases where a floor with high performance in terms of mechanical strength, fire resistance, thermal and acoustic insulation is required.
This type of core consists of a monolithic layer of anhydrous calcium sulfate reinforced with recycled cellulosic fibers, in class 0 (class A1 according to EN13501-1) reaction to fire.
The feature that guarantees the high performance is the density. The higher density it is, the harder it gets which requires solid and heavy duty machine to manufacter it.During the production procedure of a piece of such flooring, sanding is the crucial production part which matters. Our heavy duty designed sanding machines is your ideal selection for hard flooring material sanding, such as calcium sulfate/ silicate floors, SPC/WPC flooring panels, MGO panels etc.
Product Parameters

Panel weight	20-40Kg/pc
Panel density	1650-1750kg/m3
Flatness after grinding	within 0.1mm
Thickness tolerence after grinding	±0.05mm
Working efficiency:	5pcs/min
Max. working width:	650mm
Working thickness:	3-80mm
Working length:	≥500mm
Number of treating surfaces	2
Number of sanding machines	4
Working hours per day	8hours
Production capacity	1600-2000pcs/day
Total Power:	292.45kW
Total weight of the line	19540Kgs
Total length of the line	26.325m

General Information of the Grinding Line Sanding Line:
Panel density: 1650-1750kg/m3 Flatness after grinding: within 0.1mm Thickness tolerance after grinding: ±0.05mm Working efficiency: 5pcs/min Max. working width: 650mm Working thickness: 3-80mm Working length: ≥500mm Number of treating surfaces: 2 Our Advantages
1. Full automatic for loading and unloading
2. high sanding precison
3. stable operation
4. 2 years warranty from installation date
5. 24 years experienced sanding line designer.
6. complete solution with long life adhesive belt supplying.
Aspiration system suggestion:

Nos. of total dust outlet	100mm * 28
Air speed	28m/s
Total Air volumn required	30000m3/h
Suggested power	30kW

Equipment List:

S.NO.	MACHINE DESCRIPTION	NOS.
1	AUTOMATIC LOADER WITH HYDRAULIC LIFTING TABLE	1
2	1.5M CONVEYOR	1
3	3-HEAD SANDER P40--P60--P80	1
4	PANEL TURNOVER MACHINE	1
5	3-HEAD SANDER P40--P60--P80	1
6	1.5M CONVEYOR	1
7	3-HEAD SANDER P100--P120/P150--P150/P180	1
8	PANEL TURNOVER MACHINE	1
9	3-HEAD SANDER P100--P120/P150--P150/P180	1
10	1.5M CONVEYOR	1
11	AUTOMATIC LOADER WITH HYDRAULIC LIFTING TABLE	1
12	CENTRAL CONTROL STATION	1

Detailed Photos

Application
Packaging & Shipping

Company Profile
Welcome to VALENTINA EXIM Co., Ltd, a distinguished company at the forefront of innovation and excellence in the field of sanding solutions. Specializing in wide belt sanders, we take pride in offering comprehensive sanding solutions for a diverse range of materials, catering to the unique needs of industries such as plywood/MDF, veneer sheet, acoustic panels, cement fiber panels, calcium sulfate/silicate and MGO panels, metal sheet, balsa wood, PCB boards, glass fiber panels, SPC/WPC flooring, and more.Our Core Values:At VALENTINA EXIM, our core values revolve around Research and Development (R&D), exceptional service, and dedicated sales support. We understand that each material presents its own set of challenges, and our commitment to continuous improvement allows us to stay ahead in providing cutting-edge sanding solutions.Wide Belt Sanders - Our Expertise:Our flagship product, the wide belt sander, is a testament to our dedication to manufacturing excellence. These machines are designed to meet the specific requirements of various materials, ensuring precision and efficiency in the sanding process. We take pride in offering tailor-made solutions that enhance the quality and finish of your products.Complete Sanding Solutions:VALENTINA EXIM Co., Ltd goes beyond providing mere machinery; We deliver complete sanding solutions. Whether you are dealing with delicate veneer sheets, robust metal sheets, or intricate PCB boards, our range of sanding solutions is versatile and customizable. We understand the nuances of each material and offer expertise to optimize your sanding processes.Material Expertise:Our extensive experience spans a wide array of materials, including but not limited to plywood/MDF, veneer sheets, acoustic panels, cement fiber panels, calcium sulfate/silicate and MGO panels, metal sheets, balsa wood, PCB boards, glass fiber panels, SPC/WPC flooring, and more. Whatever your material requirements, VALENTINA EXIM is your reliable partner in achieving superior finishing results.Customer-Centric Approach:At the heart of our business is a customer-centric approach. We believe in building lasting relationships with our clients by providing not only high-quality sanding solutions but also unparalleled service and support. Our dedicated sales team ensures that your unique needs are understood and met with precision.Choose VALENTINA EXIM Co., Ltd for a partner that not only delivers sanding solutions but also understands the intricate details of your materials. Elevate your production processes with our wide belt sanders and experience the difference that expertise and innovation can make.VALENTINA EXIM Co., Ltd - Where Excellence Meets Innovation in Sanding Solutions. May the universe brings us together.
After Sales Service
We have our after-sales service team consisting of 7 technician. Each of our technician and engineer has learnt about sanding with us over 10 years. We assure to provide professional service for all clients and each machine from us on time, 7*24hours stand by online.
