3 Axis CNC Engraving Machine Em-870 with 24000rpm Spindle
Basic Info.
Model NO.
EM870
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
CE
Condition
New
Spindle Taper
Bt30
Spindle Motor
7.5kw
System
Syntec/Mitsubishi/Fanuc/Siemens
Max Load
400kg
Name
Cutting Mold CNC Milling Machine
X/Y/Z Speed
24/24/124 M/Min
Tool Alignment
Auto Tool Checking
Working Table
800*1000
Precision
+-0.005/300mm
Repeat Precision
+-0.003mm
Power
5.5kw 380V 3 Phase
Spindle Speed
24000 Rpm
Max Working Speed
6m/ Min
Applicable Industries
Machinery Repair Shops, Manufacturing Plant, Mold
Type
Engraving Milling Machine
Transport Package
Sea Worthy Plywood Case
Specification
3400*2100*2600
Trademark
WT
Origin
Dongguan City China Prc
HS Code
8459310000
Production Capacity
2000PCS/Year
Product Description
3 Axis CNC Engraving Machine EM-870 with 24000rpm SpindleProduct Description
CNC Engraving And Milling Machine For Steel Metal Cutting Embossing Mold Is A Tool Machine Center Which can be engraved or milled. On the basis of the engraving machine, the power of the main shaft and the servo motor is increased, the bearing capacity of the bed is increased, and the high speed of the main shaft is maintained, and more importantly, the precision is high. The engraving and milling machine is also developing towards high speed, which is generally called high-speed machine. It has stronger cutting ability and very high machining accuracy. It can also directly process materials with a hardness above HRC60 and form it at one time. It is widly used in Metal Copper Aluminum Precision Milling And Engraving.
Product Paramenters
| Item | Unit | T-540 | T-650 | T-760 | T-870 | T-1080 |
| X-axis travel | mm | 400 | 600 | 600 | 800 | 1000 |
| Y-axis travel | mm | 500 | 600 | 700 | 700 | 800 |
| Z-axis travel | mm | 200 | 260 | 280 | 350 | 500 |
| Spindle nose to table | mm | 50-220 | 50-310 | 30-290 | 70-470 | 70-470 |
| Three-axis guide width | X/Y:30 Z:25 | X/Y:30 Z:25 | X/Y/Z:30 | X/Y/Z:MSA35 | X/Y/Z:MSA35 | |
| Table size | mm | 500*400 | 600*600 | 600*700 | 800*800 | 800*1000 |
| T-slot | mm | 6*16*90 | 6*16*90 | 6*16*90 | 7*18*100 | 9*18*100 |
| Max load capability | kg | 250 | 300 | 300 | 400 | 400 |
| Standard spindle | Motorized spindle | Motorized spindle | Motorized spindle | Motorized spindle | Motorized spindle | |
| Spindle speed | rpm | 3000-24000 | 3000-24000 | 3000-24000 | 3000-24000 | 3000-24000 |
| Spindle power | kw | 3 | 3 | 3 | 5.5 | 5.5 |
| Spindle taper | ER25/BT30 | ER25/BT30 | ER25/BT30 | ER25/BT30 | ER25/BT30 | |
| Maximum cutting feed rate (X/Y/Z) | mm/min | 8000 | 8000 | 8000 | 8000 | 8000 |
| Rapid speed(X/Y/Z) | m/min | X/Y/Z:15 | X/Y/Z:15 | X/Y/Z:15 | X/Y/Z:24 | X/Y/ Z:24 |
| Ball screw diameter/pitch | mm | X/Y/Z:32/5 | X/Y/Z:32/5 | X/Y/Z:32/5 | X/Y:40/6 Z:32/5 | X/Y:40/6 Z:32/5 |
| Positioning accuracy | mm | ±0.005/300 | ±0.005/300 | ±0.005/300 | ±0.005/300 | ±0.005/300 |
| Repeatability | mm | ±0.003 | ±0.003 | ±0.003 | ±0.003 | ±0.003 |
| Air pressure | kgf/cm² | 6 | 6 | 6 | 6 | 6 |
| Net weight of machine | kg | 3200 | 3400 | 3600 | 4800 | 5300 |
| Area | mm² | 1950*1895 | 1950*1895 | 1950*1895 | 2450*2150 | 2750*2150 |
| Machine height | mm | 2355 | 2355 | 2355 | 2673 | 2673 |
| System | Syntec 21MA/E80 | |||||
