Industrial Pure Polyester Powder Coating for Metal Finish Electrostatic Paint

Product Description

BRIEF INTRODUCTION

Electrostatic polyester powder coating gives an excellently homogenous surface. Due to a high level of production control, areas of thicker paint at the edges and corners or the 'orange peel' texture usually associated with powder coating are minimized. Electrostatic polyester powder coating is a more cost effective option than PVDF coatings but not as durable. Baked at low temperatures, it is an energy efficient coating technology suitable for interior and exterior applications. Large panels, curves and complex forms can be easily coated. UV stable and highly weather resistant, its performance can be tailored to meet the demands of particular applications and various degrees of gloss can be specified. RANGE
High Gloss, Gloss, Semi Gloss & Matt
Fine Texture & Ripple
Antique Finishes and Tinted Lacquers
Metallic Effects
Sparkle Effects
Fluorescent Effects
ADVANTAGES
High solid content, excellent fullness of film
Thick coating is available
High sanding performance & good abrasion
High application efficiency & easy to apply
Primer can improve hardness of top coat & save the consumption of topcoat
SPECIFICATION

Main Material	Polyester resin,barium sulfate,titanium dioxide
Surface Type	Gloss,matte,wrinkle,sandgrain,antique,Hammer,crocodile skin,wood effect,candy,chrome,transparent,semitransparent,metallic,and special pattern
Powder Properties	Specific gravity : 1.3 - 1.75 (depend on colors)
	Average particle size : 35 - 45um
Coating Properties	Film thickness(ISO 2178) :60 - 90 μm
	Coverage:15m2 based on 60μm
	Pencil hardness: ASTM D3363,H-2H
	Adhesion :GB/T 9286-1998,0 grade
	Bending test:GB/T 6742 ,=<2mm
	Cupping test:GB/T 9753,>=7mm
	Direct and reverse impact (ASTM D2794) : > 50kg.cm
	Salt spray Resistance ( ASTM B117, 1000hrs)(Maximum undercutting ,1 mm ): No blistering or loss of adhesion
	Heat and moisture test GB/T 1740,>=1000 hours,no change
Application Schedule	Applied by : Electrostatic spraying devices
	Curing schedule :10 minutes at 200 ºC
Advantage	Good adhesion,anti-corrosion,UV resistant, strong coating film,
	Accurate colors, good leveling
Shelf Life	12 months

STORAGE CONDITIONS
Temperature: ≤30ºC
Humidity Conditions: Dry, Cool and Ventilated
Storing Requirement: Cannot be piled up over 4 cartons;
Seal the PE bag after using;
Away from VOC, fire and heat;
Validity: 6 months (If the parameters are tested to be qualified, the product still can be used expire date)
CERTIFICATE
PACKAGE AND DELIVERY
FACTORY
QC
APPLICATION
FAQ:
1.Factory or trading company?
We are Factory. We specialize in powder coating industry over 15 years, welcome friends from worldwide to visit our factory.
2.M.O.Q :
The minimum order is 500kg ,each color ≥ 100kg
3.Colors:
RAL color :we usually use RAL colors that is widely used in paint industry and easily find in market
Custom color : Color matching is available , if you have colors panel ,please send to us for matching .
4.Prices:
Prices depend on the colors and using environment ,for prices please tell us the colors and using environment (indoor use or outdoor use).
5.Time of delivery :
Production will take about 5-8 days after receipt of prepayment, it depends on the quantity.
6.Payment :
30% T/T prepayment , 70% T/T before shipment (or against BL) or LC at sight .
7.Samples:
1kg powder sample is available for each color for your testing.
Sample is free of cost,but we will highly appreciate if you pay for the courier charge.
