Woodworking 45 90 Degrees Double Saw Blade Melamine MDF Plywood Wood Cutting Machine Precision Sliding Table Panel Saw Machine

Product Description

Woodworking 45 90 degrees Double saw Blade melamine mdf plywood Wood Cutting Machine Precision Sliding Table Panel Saw Machine
Product Description

model no	F45B
max cutting length	3200mm
max cutting thickness	75mm
main saw spindle speed	4000/6000rpm
scoring saw spindle speed	8000rpm
main saw blade diameter	300mm
scoring saw blade diameter	120mm
main motor	4kw
scoring motor	0.75kw
tilting saw blade	90°/45°
weight	750kg
overall dimensions	3200*1100*1200mm

Sliding table saw machine
1,90 degree panel saw can only cut 90 degree right angle.
2,45 degree panel saw blade can be tilted, not only can cut right angle but also can effectively cut 0-45° sheet, used for solid wood furniture, panel furniture, and other manufacturers. You can choose the appropriate model according to your needs.
Features
1,The ruler to adopt the European style large ruler, stable and non-displacement, effectively ensure the precision in the cutting process of the board.
2,45 degree angle plate,cutting angle can be adjusted,saw blade can be tilted,can cut 45 degree bevel,can also cut right angle.
3,The machine adopts the main and groove double saw blades for cutting, the groove saw blade is scribed, the main saw blade is cut, the division of labor is clear, the cutting is orderly, and the cutting quality is guaranteed.
4,Heavy structure, to ensure the stability of the overall machine, better reduce its own resonance, improve the service life and cutting accuracy.
5,Feeding frame is made of aluminum tube,which has higher bearing pressure than traditional iron pipe.
Detailed Description
Detailed Pictures
Application
It is used for cross-cutting of various kinds of wood-based panels, such as veneers, particleboards, fiberboards, plywood and solid wood panels, aluminum alloys, plexiglass panels, etc.
