Combination Lathe Machine Jyp260 Jyp260L
| US$1,200.00-2,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
JYP260 JYP260L
Type
Horizontal Lathe
Processing Accessory
Metal
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Way Tool Post
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Floor-type
Precision
High Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Max.Swing Over Bed
250mm
Spindle Taper
Mt4
Spindle Bore
26mm
Transport Package
Plywood Case
Specification
3200kgs
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
84581900
Production Capacity
10 PCS/Month
Product Description
COMBINATION LATHE JYP260/JYP260L
Most popular ,widely useful combination machine
V-way bed is precision ground
Gear head enables to change speed quickly
MT4 spindle hole gets more capacity
Spindle is supported by precision bearing
T-slotted cross slide
Power longitudinal feed allows threading
Adjustable gids for slideways
Top design of gearbox gets more function
Mill head can be tilted ± 90° .
Tolerance test certificate, test flow chart included.
SPECIFICATIONS:
| MODEL | JYP260 |
| Distance between centers | 450/ 700mm |
| Swing over bed | 250mm |
| Taper of spindle bore | MT4 |
| Spindle bore | 26mm |
| Step of spindle speeds | 6 |
| Range of spindle speeds | 115-1620rpm |
| Range of inch threads | 8-56T.P.I |
| Range of metric threads | 0.4 -3.5mm |
| Travel of cross slidel | 140mm |
| Taper of tailstock quill | MT3 |
| Motor | 750W |
| Taper of spindle bore | MT2 |
| Spindle stroke | 50mm |
| Spindle speed | 50-2250rpm |
| Max.distance spindle to table | 280mm |
| Max.distance spindle to columm | 170mm |
| Head tilt | ±9 0 ° |
| Motor | 500W |
| Packing size | 1270/1510 × 670 × 1100mm |
| Net weight | 180kg / 200kg |
| STANDARD ACCESSORIES : | OPTIONAL ACCESSORIES : |
| 3-jaw chuck Dead centers Reductions sleeve Change gears Oil gun Some tools | Steady rest Follow rest Face plate 4 jaw chuck Live center Stand Lathe tools Thread chasing dial Lead screw cover Tool post cover Disc milling cutter Mill chuck Side brake |
