Single-Mode G657A2 Bend-Optimized Low Loss Bare Optical Fiber

Product Description

Single-Mode G657A2 Bend-Optimized Low Loss Bare Optical Fiber Product Description
Bending Insensitive Single-mode Fiber
YOFC bending insensitive single-mode fibre combines two attractive features: excellent low macro-bending sensitivity and low water-peak level. It is comprehensively optimized for use in O-E-S-C-L band (1260 -1625 nm). The EasyBand® Plus's bending insensitive feature not only guarantees L-band applications but also allows for easy installation without excessive care when storing the fibre especially for FTTH networks application. Bending radii in fibre guidance ports can be reduced as well as minimum bend radii in wall and corner mountings. • Extremely high bending loss resistance in the 7.5 to 15 mm bending radius range
• Full compatibility with all G.652 fibres for any applications
• Low attenuation satisfying the operation demand in O-E-S-C-L band
• Low PMD satisfying high bit-rate and long distance transmission requirements
• Low bending loss for highly demanding cable designs including ribbons
• Accurate geometrical parameters that insure low splicing loss and high splicing efficiency
• High nd-value satisfying long operational lifetime in minimum bend radius
• All types of fibre cables with different structures
• High performance optical network operating in O-E-S-C-L band
• High speed optical routes for Fiber-to-the-Home networks
• Cables with extreme low bending requirements
• Small-sized fiber cable and optical component
Product Parameters

Specifications (G657A2)
Characteristics		Conditions	Specified values	Units
Optical Characteristics
Attenuation		1310nm	≤0.35	[dB/km]
		1383nm(after H2-aging)	≤0.35	[dB/km]
		1460nm	≤0.25	[dB/km]
		1490nm	≤0.23	[dB/km]
		1550nm	≤0.21	[dB/km]
		1625nm	≤0.23	[dB/km]
Attenuation vs. Wavelength		1285-1330nm, in reference to 1310nm	≤0.03	[dB/km]
Max. α difference		1525-1575nm, in reference to 1550nm	≤0.02	[dB/km]
Zero Dispersion Wavelength(λ0)		--	1300-1324	[nm]
Zero Dispersion Slope(S0)		--	≤0.092	[ps/(nm2·km)]
PMD	Maximum Individual Fibre	--	≤0.1	[ps/√km]
	Link Design Value(M=20,Q=0.01%)	--	≤0.06	[ps/√km]
	Typical Value	--	0.04	[ps/√km]
Cable Cutoff Wavelength (λCC)		--	≤1260	[nm]
Mode Field Diameter(MFD)		1310nm	8.4-9.2	[μm]
		1550nm	9.3-10.3	[μm]
Effective Group Index of Refraction(Neff )		1310nm	1.466	--
		1550nm	1.467	--
Point Discontinuities		1310nm	≤0.05	[dB]
		1550nm	≤0.05	[dB]
Geometrical Characteristics
Cladding Diameter		--	125.0±0.7	[μm]
Cladding Non-Circularity		--	≤0.7	[%]
Coating Diameter		--	235-245	[μm]
Coating-Cladding Concentricity Error		--	≤12.0	[μm]
Coating Non-Circularity		--	≤6.0	[%]
Core-Cladding Concentricity Error		--	≤0.5	[μm]
Curl(radius)		--	≥4	[m]
Delivery Length		--	Up to 50.4	[km/reel]
Environmental Characteristics		1310nm, 1550nm & 1625nm
Temperature Dependence Induced Attenuation		-60ºC to +85ºC	≤0.05	[dB/km]
Temperature-Humidity Cycling Induced Attenuation		-10°C to +85°C, 98% RH	≤0.05	[dB/km]
Watersoak Dependence Induced Attenuation		23°C, for 30 days	≤0.05	[dB/km]
Damp Heat Dependence Induced Attenuation		85°C and 85% RH, for 30 days	≤0.05	[dB/km]
Dry Heat Aging		85ºC, for 30 days	≤0.05	[dB/km]
Mechanical Specification
Proof Test		--	≥9.0	[N]
		--	≥1.0	[%]
		--	≥100	[kpsi]
Macro-bend Induced Attenuation	10 Turns Around a Mandrel of 15 mm Radius	1550nm	≤0.03	[dB]
	10 Turns Around a Mandrel of 15 mm Radius	1625nm	≤0.1	[dB]
	1 Turn Around a Mandrel of 10 mm Radius	1550nm	≤0.1	[dB]
	1 Turn Around a Mandrel of 10 mm Radius	1625nm	≤0.2	[dB]
	1 Turn Around a Mandrel of 7.5 mm Radius	1550nm	≤0.5	[dB]
	1 Turn Around a Mandrel of 7.5 mm Radius	1625nm	≤1.0	[dB]
Coating Strip Force		typical average force	1.5	[N]
		peak force	1.3-8.9	[N]
Dynamic Fatigue Parameter(nd)		--	≥20	--
