360 Degree All-Round Flip Planetary Ball Mill, Even Grinding Without Dead Angle, Non-Sinking Bottom, Non-Stick Can

Product Description

360 degree all-round flip planetary ball mill, even grinding without dead angle,Non-sinking bottom, non-stick can
Description of Omnidirectional planetary ball mill:
The omnidirectional planetary ball mill is based on the vertical planetary ball mill, and the planetary gear mechanism flip function is added. While the planet disk and the material and grinding balls in the ball mill tank do planetary movement, they can also do 360 ° in a fixed space. Turn over to achieve multi-dimensional and multi-directional movement of the grinding balls and materials in the ball mill jar, improve the degree of random movement of the grinding balls and materials. Sinking bottom and sticky cans.
Features of Omnidirectional Planetary Ball Mill
The equipment is designed by professional appearance, the shell is cut by high-precision laser, CNC bending and forming, generous and exquisite, high-end and stable, the planetary discs and structural components are processed by CNC processing, and the nitriding metal heat treatment process ensures that the rotating shaft is wear-resistant To prevent shaft breakage, the transmission gear adopts high-temperature wear-resistant non-metallic and metal combination precision gears, which are lubricated with grease. Optional our company's automatic lubricating grease device. The ball milling tank can be taken on the equipment and placed in the tank. The corresponding positions of the picking and placing cans can be positioned to improve production efficiency.
Technical specifications of Omnidirectional planetary ball mill:

transfer method	gear drive
Way of working	Two or four ball mills work simultaneously
Maximum sample loading	Two thirds of the volume of the ball mill
Ball mill volume	0.05L-10L per can, total volume 0.2L-40L
Feeding size	Loam material ≤10mm, other materials ≤3mm
Discharge size	Up to 0.1μm
Speed ratio (revolution: rotation)	See main parameters of planetary ball mill for details
Speed (rotation)	See main parameters of planetary ball mill for details
Speed mode	Brand inverter stepless speed regulation

Technical parameters(1)

Model	Specification	Specification of ball milling tank available	Quantity	Matching ball milling tank(vacuum ball milling tank)	Standard ball milling tank locking device
OPBM-0.4	0.4	50-100ml	4	50-100ml	Self-locking
OPBM-1	1	50-250ml	4	50-250ml	Self-locking
OPBM-2	2	250-1000ml	4	250-1000L	Self-locking
OPBM-4	4	1-1.5L	4	1-1.5L	Self-locking
OPBM-6	6	1-2L	4	1-2L	Self-locking
OPBM-8	8	1-2.5L	4	1-2.5L	Self-locking
OPBM-10	10	1-3L	4	1-3L	Self-locking
OPBM-12	12	2-4L	4	2-4L	Self-locking
OPBM-16	16	2-5L	4	2-5L	Self-locking
OPBM-20	20	5-10L	4	5-10L	Self-locking
OPBM-40	40	5-10L	4	5-10L	Self-locking

Technical parameters(2)

Model	Equipment power (Simplex)	Motor power (KW)	Rotating motor power	Operation setting total time (min)	Alternating running time (min)	Adjustable speed revolution (rpm) rotation (rpm)
OPBM-0.4	220V-50HZ	0.25	0.09	1-9999	1-9999	47-465 94-930
OPBM-1	220V -50HZ	0.75	0.09	1-9999	1-9999	35-370 70-740
OPBM-2	220V -50HZ	0.75	0.09	1-9999	1-9999	35-370 70-740
OPBM-4	220V -50HZ	0.75	0.09	1-9999	1-9999	35-370 70-740
OPBM-6	220V -50HZ	0.75	0.12	1-9999	1-9999	35-370 70-740
OPBM-8	220V -50HZ	1.5	0.12	1-9999	1-9999	35-320 70-640
OPBM-10	220V -50HZ	1.5	0.12	1-9999	1-9999	35-320 70-640
OPBM-12	220V -50HZ	1.5	0.12	1-9999	1-9999	35-320 70-640
OPBM-16	220V -50HZ	3	0.12	1-9999	1-9999	30-255 60-510
OPBM-20	220V -50HZ	4	0.75	1-9999	1-9999	25-215 50-530
OPBM-40	220V -50HZ	5.5	0.75	1-9999	1-9999	20-195 40-390

Technical parameter(3)

Model	Basic panel (optional smart, touch screen)	Lubrication method	Speed mode	equipment weight (Kg)	Equipment size Length *Width *Height (mm)	Noise≤db
OPBM-0.4	intelligent	grease	Frequency	140	900X570X650	55±5
OPBM-1	intelligent	grease	Frequency	280	1330X770X810	60±5
OPBM-2	intelligent	grease	Frequency	280	1330X770X810	60±5
OPBM-4	intelligent	grease	Frequency	285	1330X770X810	60±5
OPBM-6	intelligent	grease	Frequency	290	1330X770X810	60±5
OPBM-8	intelligent	grease	Frequency	345	1350X850X900	65±5
OPBM-10	intelligent	grease	Frequency	345	1350X850X900	65±5
OPBM-12	intelligent	grease	Frequency	350	1350X850X900	65±5
OPBM-16	intelligent	grease	Frequency	400	1550X940X1050	68±5
OPBM-20	intelligent	grease	Frequency	710	1700X1200X1250	68±5
OPBM-40	intelligent	grease	Frequency	1000	1900X1450X1400	68±5

Reference pictures of Omnidirectional planetary ball mill:
Q. Are you a manufacturer or a trading company?
A. We are professional laboratory instrument manufacturers, have their own design team and factory, have mature technical experience, and can guarantee the quality of products and the optimal price.
Q. How is your company's product after-sales service system?
A. The product warranty period is 12 months, we can provide lifetime maintenance. We have professional pre-sales and after-sales departments that can respond to you within 24 hours to resolve any technical issues.
Q. How long is your delivery time? If I want to customize the instrument, how long does it take?
A.1. If the goods are in stock, it is 5-10 days. 2. We can provide customized services for our customers. It usually takes 30-60 days depending on the specifications of the custom instrument.
Q. Our country's power supply and plug are different. How do you solve it?
A. We can supply a transformer and plug according to your local requirements according to the power plug of different countries.
Q. How to pay?
A.T / T, L / C, D / P, etc., it is recommended to use ****** Trade Guarantee.
Q. How is the package of goods? Delivery methods?
A.1. Standard export fumigation sign wooden box packaging 2. Express, air, sea shipping according to customer requirements, find the most suitable way.
More questions, please contact customer service
